Specifications
| Clamp 30 | |
| Clamp 50 | |
| Flange Diameter (mm) | 76.2 |
| Jaw opening angle measurement (Degree) | 9 |
| Length (mm) | 237 |
| Mounting Angle (degrees) | 9 |
| Mounting bore angle measurement (degree) | 9 |
| Number of mounting bores 0 | |
| Number of Teeth 9 | |
| Number of threaded holes 2 | |
| Pinion Rest Position (mm) | 21 |
| Position/Degree rechts | |
| Rated Power (kW) | 1.7 |
| Rotation Direction Clockwise rotation | |
| Starter Type Self-supporting | |
| Thread Size 1 M10x1.5 | |
Clamp 30, Clamp 50, Flange Diameter [mm] 76,2, Jaw opening angle measurement [Degree] 9, Length [mm] 237, Mounting Angle [degrees] 9, Mounting bore angle measurement [degree] 9, Number of mounting bores 0, Number of Teeth 9, Number of threaded holes 2, Pinion Rest Position [mm] 21, Position/Degree rechts, Rated Power [kW] 1,7, Rotation Direction Clockwise rotation, Starter Type Self-supporting, Thread Size 1 M10x1.5, Thread Size M10, Voltage [V] 12
