Specifications
| Alternator Charging Current (A) | 120 |
| Alternator Type excl. vacuum pump | |
| Belt Pulley Ø (mm) | 45.3 |
| Fastening Type Single pivoted lever | |
| Length (mm) | 198.9 |
| Number of grooves 8 | |
| Pulleys with belt pulley | |
| Pulleys with multi-belt pulley | |
| Recommended additional repairs V-Belt/V-Ribbed Belt | |
| Rotation Direction Clockwise rotation | |
| Voltage (V) | 14 |
Alternator Charging Current [A] 120, Alternator Type excl. vacuum pump, Belt Pulley Ø [mm] 45,3, Fastening Type Single pivoted lever, Length [mm] 198,9, Number of grooves 8, Pulleys with belt pulley, Pulleys with multi-belt pulley, Recommended additional repairs V-Belt/V-Ribbed Belt, Rotation Direction Clockwise rotation, Voltage [V] 14
Fits: MERCEDES-BENZ
Fits: MERCEDES-BENZ
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| MERCEDES-BENZ | S-CLASS (W140) | 600 SE, SEL (140.056, 140.057) | 1991 – 1998 | 5987 | 300 | 408 |
| MERCEDES-BENZ | S-CLASS (W140) | S 420 | 1991 – 1998 | 4196 | 214 | 291 |
| MERCEDES-BENZ | S-CLASS (W140) | S 320 | 1991 – 1998 | 3199 | 162 | 220 |
| MERCEDES-BENZ | S-CLASS (W140) | S 300 Turbo-D (140.135) | 1991 – 1998 | 2996 | 130 | 177 |
| MERCEDES-BENZ | S-CLASS (W140) | S 350 Turbo-D (140.134) | 1991 – 1998 | 3449 | 110 | 150 |
| MERCEDES-BENZ | S-CLASS (W140) | S 600 (140.056, 140.057) | 1991 – 1998 | 5987 | 290 | 394 |
| MERCEDES-BENZ | S-CLASS (W140) | 500 SE, SEL (140.050, 140.051) | 1991 – 1998 | 4973 | 240 | 326 |
| MERCEDES-BENZ | S-CLASS (W140) | S 500 (140.050, 140.051) | 1991 – 1998 | 4973 | 235 | 320 |
| MERCEDES-BENZ | S-CLASS (W140) | 400 SE, SEL/S420 (140.042, 140.043) | 1991 – 1998 | 4196 | 210 | 286 |
| MERCEDES-BENZ | S-CLASS (W140) | S 420 (140.042, 140.043) | 1991 – 1998 | 4196 | 205 | 279 |
| MERCEDES-BENZ | S-CLASS (W140) | 300 SE, SEL/S320 (140.032, 140.033) | 1991 – 1998 | 3199 | 170 | 231 |
| MERCEDES-BENZ | S-CLASS (W140) | 300 SE 2.8 (140.028) | 1991 – 1998 | 2799 | 145 | 197 |
| MERCEDES-BENZ | S-CLASS (W140) | S 280 (140.028) | 1991 – 1998 | 2799 | 142 | 193 |
| MERCEDES-BENZ | S-CLASS Coupe (C140) | 500 SEC / CL 500 (140.070) | 1992 – 1999 | 4973 | 235 | 320 |
| MERCEDES-BENZ | S-CLASS Coupe (C140) | SEC/CL 600 (140.076) | 1992 – 1999 | 5987 | 290 | 394 |
| MERCEDES-BENZ | S-CLASS Coupe (C140) | SEC/CL 420 (140.063) | 1992 – 1999 | 4196 | 205 | 279 |
| MERCEDES-BENZ | S-CLASS Coupe (C140) | CL 600 | 1992 – 1999 | 5987 | 270 | 367 |
| MERCEDES-BENZ | S-CLASS Coupe (C140) | SEC/CL 600 | 1992 – 1999 | 5987 | 300 | 408 |
