Specifications
| Bolt Hole Circle Ø (mm) | 100 |
| Bore Diameter up to (mm) | 15.6 |
| Brake Disc Thickness (mm) | 22 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 65. fulfils ECE norm ECE-R90 |
| Height (mm) | 36.9 |
| Machining High-carbon | |
| Minimum thickness (mm) | 19 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 256 |
| Supplementary Article/Info 2 with bolts/screws | |
| Surface Coated | |
Bolt Hole Circle Ø [mm] 100, Bore Diameter up to [mm] 15,6, Brake Disc Thickness [mm] 22, Brake Disc Type Vented, Centering Diameter [mm] 65, fulfils ECE norm ECE-R90, Height [mm] 36,9, Machining High-carbon, Minimum thickness [mm] 19, Number of Holes 5, Outer Diameter [mm] 256, Supplementary Article/Info 2 with bolts/screws, Surface Coated
