Specifications
| Bolt Hole Circle Ø (mm) | 100 |
| Bore Diameter up to (mm) | 15.7 |
| Brake Disc Thickness (mm) | 22 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 65. fulfils ECE norm ECE-R90 |
| Height (mm) | 44.2 |
| Machining High-carbon | |
| Minimum thickness (mm) | 19 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 256 |
| Surface Coated | |
Bolt Hole Circle Ø [mm] 100, Bore Diameter up to [mm] 15,7, Brake Disc Thickness [mm] 22, Brake Disc Type Vented, Centering Diameter [mm] 65, fulfils ECE norm ECE-R90, Height [mm] 44,2, Machining High-carbon, Minimum thickness [mm] 19, Number of Holes 5, Outer Diameter [mm] 256, Surface Coated
Fits: AUDI, BMW, DAIHATSU, LEXUS, SEAT, SKODA, VW, WULING (SGMW)
Fits: AUDI, BMW, DAIHATSU, LEXUS, SEAT, SKODA, VW, WULING (SGMW)
Interchangeable Part Numbers
OE Numbers — AUDI
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| AUDI | A1 City Carver (GBH) | 25 TFSI | 2019 – 2022 | 999 | 70 | 95 |
| AUDI | A1 City Carver (GBH) | 30 TFSI | 2019 – 2022 | 999 | 85 | 116 |
| AUDI | A1 City Carver (GBH) | 35 TFSI | 2019 – 2022 | 1498 | 110 | 150 |
| AUDI | A1 City Carver (GBH) | 30 TFSI | 2019 – 2022 | 999 | 81 | 110 |
