Specifications
| Bolt Hole Circle Ø (mm) | 114.3 |
| Bore Diameter up to (mm) | 12.8 |
| Brake Disc Thickness (mm) | 28 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 68. fulfils ECE norm ECE-R90 |
| Height (mm) | 53.8 |
| Machining High-carbon | |
| Minimum thickness (mm) | 26 |
| Number of Holes 6 | |
| Outer Diameter (mm) | 320 |
| Surface Coated | |
Bolt Hole Circle Ø [mm] 114,3, Bore Diameter up to [mm] 12,8, Brake Disc Thickness [mm] 28, Brake Disc Type Vented, Centering Diameter [mm] 68, fulfils ECE norm ECE-R90, Height [mm] 53,8, Machining High-carbon, Minimum thickness [mm] 26, Number of Holes 6, Outer Diameter [mm] 320, Surface Coated
Fits: MERCEDES-BENZ
Fits: MERCEDES-BENZ
Supplier Cross-References
Interchangeable Part Numbers
OE Numbers — MERCEDES-BENZ
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| MERCEDES-BENZ | X-CLASS (470) | X 220 d (470.210) | 2017 – 2020 | 2298 | 120 | 163 |
| MERCEDES-BENZ | X-CLASS (470) | X 220 d 4-matic (470.211) | 2017 – 2020 | 2298 | 120 | 163 |
| MERCEDES-BENZ | X-CLASS (470) | X 250 d 4-matic (470.231) | 2017 – 2020 | 2298 | 140 | 190 |
| MERCEDES-BENZ | X-CLASS (470) | X 250 d (470.230) | 2017 – 2020 | 2298 | 140 | 190 |
| MERCEDES-BENZ | X-CLASS (470) | X 350 d 4-matic (470.252) | 2017 – 2020 | 2987 | 190 | 258 |
