Specifications
| Bolt Hole Circle Ø (mm) | 112 |
| Bore Diameter up to (mm) | 15.2 |
| Brake Disc Thickness (mm) | 30 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 67. fulfils ECE norm ECE-R90 |
| Height (mm) | 51.1 |
| Machining High-carbon | |
| Minimum thickness (mm) | 27.4 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 330 |
| Surface Coated | |
Bolt Hole Circle Ø [mm] 112, Bore Diameter up to [mm] 15,2, Brake Disc Thickness [mm] 30, Brake Disc Type Vented, Centering Diameter [mm] 67, fulfils ECE norm ECE-R90, Height [mm] 51,1, Machining High-carbon, Minimum thickness [mm] 27,4, Number of Holes 5, Outer Diameter [mm] 330, Surface Coated
Fits: MERCEDES-BENZ
Fits: MERCEDES-BENZ
Interchangeable Part Numbers
OE Numbers — MERCEDES-BENZ
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| MERCEDES-BENZ | EQB (X243) | EQB 350 4-matic (243.612) | 2021 – present | — | 215 | 292 |
| MERCEDES-BENZ | EQB (X243) | EQB 300 4-matic (243.608, 243.609) | 2021 – present | — | 168 | 228 |
| MERCEDES-BENZ | EQB (X243) | EQB 250 (243.601) | 2021 – present | — | 140 | 190 |
| MERCEDES-BENZ | EQB (X243) | EQB 250+ (243.602) | 2021 – present | — | 140 | 190 |
| MERCEDES-BENZ | EQB (X243) | EQB 350 4-matic (243.613) | 2021 – present | — | 215 | 292 |
