Specifications
| Bolt Hole Circle Ø (mm) | 100 |
| Bore Diameter up to (mm) | 12.7 |
| Brake Disc Thickness (mm) | 17 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 60 |
| Height (mm) | 49.2 |
| Minimum thickness (mm) | 15 |
| Number of Holes 4 | |
| Outer Diameter (mm) | 227 |
Bolt Hole Circle Ø [mm] 100, Bore Diameter up to [mm] 12,7, Brake Disc Thickness [mm] 17, Brake Disc Type Vented, Centering Diameter [mm] 60, Height [mm] 49,2, Minimum thickness [mm] 15, Number of Holes 4, Outer Diameter [mm] 227
