Specifications
| Bolt Hole Circle Ø (mm) | 100 |
| Bore Diameter up to (mm) | 12.5 |
| Brake Disc Thickness (mm) | 10 |
| Brake Disc Type solid | |
| Centering Diameter (mm) | 64 |
| Fitting Position Front Axle | |
| Fitting Position Rear Axle | |
| Height (mm) | 41 |
| Minimum thickness (mm) | 9 |
| Number of Holes 4 | |
| Outer Diameter (mm) | 208 |
Bolt Hole Circle Ø [mm] 100, Bore Diameter up to [mm] 12,5, Brake Disc Thickness [mm] 10, Brake Disc Type solid, Centering Diameter [mm] 64, Fitting Position Front Axle, Fitting Position Rear Axle, Height [mm] 41, Minimum thickness [mm] 9, Number of Holes 4, Outer Diameter [mm] 208
