Specifications
| Bolt Hole Circle Ø (mm) | 108 |
| Bore Diameter up to (mm) | 13.8 |
| Brake Disc Thickness (mm) | 25 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 63.6 |
| Height (mm) | 48.5 |
| Minimum thickness (mm) | 24 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 300 |
Bolt Hole Circle Ø [mm] 108, Bore Diameter up to [mm] 13,8, Brake Disc Thickness [mm] 25, Brake Disc Type Vented, Centering Diameter [mm] 63,6, Height [mm] 48,5, Minimum thickness [mm] 24, Number of Holes 5, Outer Diameter [mm] 300
