Specifications
| Bolt Hole Circle Ø (mm) | 120 |
| Bore Diameter up to (mm) | 16.7 |
| Brake Disc Thickness (mm) | 20 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 75 |
| Height (mm) | 69 |
| Minimum thickness (mm) | 18.4 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 330 |
Bolt Hole Circle Ø [mm] 120, Bore Diameter up to [mm] 16,7, Brake Disc Thickness [mm] 20, Brake Disc Type Vented, Centering Diameter [mm] 75, Height [mm] 69, Minimum thickness [mm] 18,4, Number of Holes 5, Outer Diameter [mm] 330
