Specifications
| Bolt Hole Circle Ø (mm) | 112 |
| Bore Diameter up to (mm) | 15.2 |
| Brake Disc Thickness (mm) | 28 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 67 |
| Height (mm) | 54.6 |
| Minimum thickness (mm) | 25.4 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 295.3 |
Bolt Hole Circle Ø [mm] 112, Bore Diameter up to [mm] 15,2, Brake Disc Thickness [mm] 28, Brake Disc Type Vented, Centering Diameter [mm] 67, Height [mm] 54,6, Minimum thickness [mm] 25,4, Number of Holes 5, Outer Diameter [mm] 295,3
