Specifications
| Bolt Hole Circle Ø (mm) | 112 |
| Bore Diameter up to (mm) | 15.4 |
| Brake Disc Thickness (mm) | 28 |
| Brake Disc Type internally vented | |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 67 |
| Height (mm) | 64.5 |
| Minimum thickness (mm) | 25.4 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 295.2 |
Bolt Hole Circle Ø [mm] 112, Bore Diameter up to [mm] 15,4, Brake Disc Thickness [mm] 28, Brake Disc Type internally vented, Brake Disc Type Vented, Centering Diameter [mm] 67, Height [mm] 64,5, Minimum thickness [mm] 25,4, Number of Holes 5, Outer Diameter [mm] 295,2
Fits: MERCEDES-BENZ
Fits: MERCEDES-BENZ
Interchangeable Part Numbers
OE Numbers — MERCEDES-BENZ
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| MERCEDES-BENZ | C-CLASS (W204) | C 180 CGI (204.049) | 2007 – 2015 | 1796 | 115 | 156 |
| MERCEDES-BENZ | C-CLASS (W204) | C 350 CGI (204.065) | 2007 – 2015 | 3498 | 215 | 292 |
| MERCEDES-BENZ | C-CLASS (W204) | C 250 CDI (204.003) | 2007 – 2015 | 2143 | 150 | 204 |
| MERCEDES-BENZ | C-CLASS (W204) | C 220 CDI (204.002) | 2007 – 2015 | 2143 | 125 | 170 |
| MERCEDES-BENZ | C-CLASS (W204) | C 350 CDI (204.022) | 2007 – 2015 | 2987 | 165 | 224 |
| MERCEDES-BENZ | C-CLASS (W204) | C 350 CDI 4-matic (204.089) | 2007 – 2015 | 2987 | 165 | 224 |
| MERCEDES-BENZ | C-CLASS (W204) | C 250 CGI (204.047) | 2007 – 2015 | 1796 | 150 | 204 |
| MERCEDES-BENZ | C-CLASS (W204) | C 300 (204.054) | 2007 – 2015 | 2996 | 170 | 231 |
| MERCEDES-BENZ | C-CLASS (W204) | C 300 4-matic (204.081) | 2007 – 2015 | 2996 | 170 | 231 |
| MERCEDES-BENZ | C-CLASS (W204) | C 350 CDI (204.025) | 2007 – 2015 | 2987 | 170 | 231 |
| MERCEDES-BENZ | C-CLASS (W204) | C 350 CDI 4-matic (204.092) | 2007 – 2015 | 2987 | 170 | 231 |
| MERCEDES-BENZ | C-CLASS (W204) | C 180 Kompressor (204.044, 204.045) | 2007 – 2015 | 1597 | 115 | 156 |
| MERCEDES-BENZ | C-CLASS (W204) | C 200 CGI (204.048) | 2007 – 2015 | 1796 | 135 | 184 |
| MERCEDES-BENZ | C-CLASS (W204) | C 220 CDI (204.008) | 2007 – 2015 | 2148 | 120 | 163 |
| MERCEDES-BENZ | C-CLASS (W204) | C 63 AMG (204.077) | 2007 – 2015 | 6208 | 373 | 507 |
| MERCEDES-BENZ | C-CLASS (W204) | C 63 AMG DR 520 | 2007 – 2015 | 6208 | 383 | 520 |
| MERCEDES-BENZ | C-CLASS (W204) | C 220 CDI 4-matic (204.084) | 2007 – 2015 | 2143 | 125 | 170 |
| MERCEDES-BENZ | C-CLASS (W204) | C 220 CDI (204.002) | 2007 – 2015 | 2143 | 120 | 163 |
| MERCEDES-BENZ | C-CLASS (W204) | C 180 CGI (204.031) | 2007 – 2015 | 1595 | 115 | 156 |
| MERCEDES-BENZ | C-CLASS (W204) | C 300 (204.055) | 2007 – 2015 | 3498 | 185 | 252 |
| MERCEDES-BENZ | C-CLASS (W204) | C 300 4-matic (204.080) | 2007 – 2015 | 3498 | 185 | 252 |
| MERCEDES-BENZ | C-CLASS (W204) | C 300 Flexfuel | 2007 – 2015 | 2996 | 170 | 231 |
| MERCEDES-BENZ | C-CLASS (W204) | C 320 CDI (204.022) | 2007 – 2015 | 2987 | 165 | 224 |
| MERCEDES-BENZ | C-CLASS (W204) | C 200 CDI (204.001) | 2007 – 2015 | 2143 | 100 | 136 |
| MERCEDES-BENZ | C-CLASS (W204) | C 250 CDI 4-matic (204.082) | 2007 – 2015 | 2143 | 150 | 204 |
| MERCEDES-BENZ | C-CLASS (W204) | C 300 CDI 4-matic (204.092) | 2007 – 2015 | 2987 | 170 | 231 |
| MERCEDES-BENZ | C-CLASS (W204) | C 350 (204.057) | 2007 – 2015 | 3498 | 225 | 306 |
| MERCEDES-BENZ | C-CLASS (W204) | C 350 4-matic (204.088) | 2007 – 2015 | 3498 | 225 | 306 |
| MERCEDES-BENZ | C-CLASS (W204) | C 350 CDI (204.023) | 2007 – 2015 | 2987 | 195 | 265 |
| MERCEDES-BENZ | C-CLASS (W204) | C 200 (204.048) | 2007 – 2015 | 1796 | 137 | 186 |
| MERCEDES-BENZ | C-CLASS (W204) | C 63 AMG (204.077) | 2007 – 2015 | 6208 | 358 | 487 |
| MERCEDES-BENZ | C-CLASS (W204) | C 200 CDI (204.007, 204.006) | 2007 – 2015 | 2148 | 100 | 136 |
| MERCEDES-BENZ | C-CLASS (W204) | C 220 CDI (204.008) | 2007 – 2015 | 2148 | 125 | 170 |
| MERCEDES-BENZ | C-CLASS (W204) | C 180 CDI (204.000) | 2007 – 2015 | 2143 | 88 | 120 |
| MERCEDES-BENZ | C-CLASS (W204) | C 180 Kompressor (204.046) | 2007 – 2015 | 1796 | 115 | 156 |
| MERCEDES-BENZ | C-CLASS (W204) | C 200 Kompressor (204.041) | 2007 – 2015 | 1796 | 135 | 184 |
| MERCEDES-BENZ | C-CLASS (W204) | C 230 (204.052) | 2007 – 2015 | 2496 | 150 | 204 |
| MERCEDES-BENZ | C-CLASS (W204) | C 280 (204.054) | 2007 – 2015 | 2996 | 170 | 231 |
| MERCEDES-BENZ | C-CLASS (W204) | C 350 (204.056) | 2007 – 2015 | 3498 | 200 | 272 |
| MERCEDES-BENZ | C-CLASS (W204) | C 230 4-matic (204.085) | 2007 – 2015 | 2496 | 150 | 204 |
| MERCEDES-BENZ | C-CLASS (W204) | C 280 4-matic (204.081) | 2007 – 2015 | 2996 | 170 | 231 |
| MERCEDES-BENZ | C-CLASS (W204) | C 350 4-matic (204.087) | 2007 – 2015 | 3498 | 200 | 272 |
| MERCEDES-BENZ | C-CLASS (W204) | C 320 CDI 4-matic (204.089) | 2007 – 2015 | 2987 | 165 | 224 |
| MERCEDES-BENZ | C-CLASS (W204) | C 63 AMG (204.077) | 2007 – 2015 | 6208 | 336 | 457 |
