Specifications
| Bolt Hole Circle Ø (mm) | 100 |
| Bore Diameter up to (mm) | 14.5 |
| Brake Disc Thickness (mm) | 22 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 55 |
| Height (mm) | 46.3 |
| Minimum thickness (mm) | 20 |
| Number of Holes 4 | |
| Outer Diameter (mm) | 249 |
Bolt Hole Circle Ø [mm] 100, Bore Diameter up to [mm] 14,5, Brake Disc Thickness [mm] 22, Brake Disc Type Vented, Centering Diameter [mm] 55, Height [mm] 46,3, Minimum thickness [mm] 20, Number of Holes 4, Outer Diameter [mm] 249
