Specifications
| Bolt Hole Circle Ø (mm) | 107.95 |
| Bore Diameter up to (mm) | 15.7 |
| Brake Disc Thickness (mm) | 11 |
| Brake Disc Type solid | |
| Centering Diameter (mm) | 63.55 |
| Height (mm) | 51 |
| Minimum thickness (mm) | 9.5 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 316 |
Bolt Hole Circle Ø [mm] 107,95, Bore Diameter up to [mm] 15,7, Brake Disc Thickness [mm] 11, Brake Disc Type solid, Centering Diameter [mm] 63,55, Height [mm] 51, Minimum thickness [mm] 9,5, Number of Holes 5, Outer Diameter [mm] 316
