Specifications
| Bolt Hole Circle Ø (mm) | 112 |
| Bore Diameter up to (mm) | 15.4 |
| Brake Disc Thickness (mm) | 22 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 56 |
| Height (mm) | 48.2 |
| Minimum thickness (mm) | 20 |
| Number of Holes 9 | |
| Outer Diameter (mm) | 310 |
Bolt Hole Circle Ø [mm] 112, Bore Diameter up to [mm] 15,4, Brake Disc Thickness [mm] 22, Brake Disc Type Vented, Centering Diameter [mm] 56, Height [mm] 48,2, Minimum thickness [mm] 20, Number of Holes 9, Outer Diameter [mm] 310
