Specifications
| Bolt Head Diameter (mm) | 24.0 |
| Bolt Length (mm) | 62.0 |
| Component Number 1. R1.75 IF Cr | |
| Component Number 2. NM 2.0 | |
| Component Number 3. DSF 3.5 Cr | |
| Compression Height (mm) | 42.9 |
| Cylinder Bore (mm) | 89.5 |
| Length (mm) | 82.9 |
| Net Weight (g) | 615 |
| Packaging height (cm) | 12.80 |
| Packaging length (cm) | 9.5 |
| Packaging width (cm) | 9.50 |
| Piston Clearance (mm) | 0.03 |
| Production Number 89 V 38 | |
| Recess Depth 1 (mm) | 2.45 |
| Surface Tin-plated | |
Bolt Head Diameter [mm] 24,0, Bolt Length [mm] 62,0, Component Number 1. R1.75 IF Cr, Component Number 2. NM 2.0, Component Number 3. DSF 3.5 Cr, Compression Height [mm] 42,9, Cylinder Bore [mm] 89,5, Length [mm] 82,9, Net Weight [g] 615, Packaging height [cm] 12,80, Packaging length [cm] 9,5, Packaging width [cm] 9,50, Piston Clearance [mm] 0,03, Production Number 89 V 38, Recess Depth 1 [mm] 2,45, Surface Tin-plated, Top Land Height [mm] 9,1
Fits: MERCEDES-BENZ
Fits: MERCEDES-BENZ
Interchangeable Part Numbers
OE Numbers — MERCEDES-BENZ 102 030 53
OE Numbers — MERCEDES-BENZ
OE Numbers — MERCEDES-BENZ 102 030 76
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| MERCEDES-BENZ | 123 Saloon (W123) | 250 (123.026) | 1976 – 1985 | 2525 | 95 | 129 |
| MERCEDES-BENZ | 123 Saloon (W123) | 300 D | 1976 – 1985 | 2998 | 62 | 84 |
| MERCEDES-BENZ | 123 Saloon (W123) | 300 D | 1976 – 1985 | 2998 | 57 | 77 |
| MERCEDES-BENZ | 123 Saloon (W123) | 280 E | 1976 – 1985 | 2778 | 104 | 141 |
| MERCEDES-BENZ | 123 Saloon (W123) | 280 E | 1976 – 1985 | 2746 | 106 | 144 |
| MERCEDES-BENZ | 123 Saloon (W123) | 240 D | 1976 – 1985 | 2404 | 46 | 62 |
| MERCEDES-BENZ | 123 Saloon (W123) | 230 | 1976 – 1985 | 2307 | 69 | 93 |
| MERCEDES-BENZ | 123 Saloon (W123) | 200 | 1976 – 1985 | 1988 | 62 | 84 |
| MERCEDES-BENZ | 123 Saloon (W123) | 300 Turbo-D (123.133) | 1976 – 1985 | 2998 | 92 | 125 |
| MERCEDES-BENZ | 123 Saloon (W123) | 300 D (123.130) | 1976 – 1985 | 2998 | 65 | 88 |
| MERCEDES-BENZ | 123 Saloon (W123) | 300 D (123.130) | 1976 – 1985 | 2998 | 59 | 80 |
| MERCEDES-BENZ | 123 Saloon (W123) | 240 D (123.123) | 1976 – 1985 | 2399 | 48 | 65 |
| MERCEDES-BENZ | 123 Saloon (W123) | 240 D (123.123) | 1976 – 1985 | 2399 | 53 | 72 |
| MERCEDES-BENZ | 123 Saloon (W123) | 220 D (123.126) | 1976 – 1985 | 2197 | 44 | 60 |
| MERCEDES-BENZ | 123 Saloon (W123) | 200 (123.020) | 1976 – 1985 | 1988 | 69 | 94 |
| MERCEDES-BENZ | 123 Saloon (W123) | 200 | 1976 – 1985 | 1996 | 74 | 101 |
| MERCEDES-BENZ | 123 Saloon (W123) | 200 (123.220) | 1976 – 1985 | 1996 | 80 | 109 |
| MERCEDES-BENZ | 123 Saloon (W123) | 230 E (123.223) | 1976 – 1985 | 2299 | 100 | 136 |
| MERCEDES-BENZ | 123 Saloon (W123) | 230 (123.023) | 1976 – 1985 | 2307 | 80 | 109 |
| MERCEDES-BENZ | 123 Saloon (W123) | 250 (123.026) | 1976 – 1985 | 2525 | 103 | 140 |
| MERCEDES-BENZ | 123 Saloon (W123) | 220 D | 1976 – 1985 | 2197 | 49 | 67 |
| MERCEDES-BENZ | 123 Saloon (W123) | 200 D | 1976 – 1985 | 1988 | 44 | 60 |
| MERCEDES-BENZ | 123 Saloon (W123) | 200 D (123.120) | 1976 – 1985 | 1988 | 40 | 55 |
| MERCEDES-BENZ | 123 Saloon (W123) | 280 E (123.033) | 1976 – 1985 | 2746 | 136 | 185 |
| MERCEDES-BENZ | 123 Saloon (W123) | 280 E (123.033) | 1976 – 1985 | 2746 | 130 | 177 |
| MERCEDES-BENZ | 123 Saloon (W123) | 280 (123.030) | 1976 – 1985 | 2746 | 115 | 156 |
| MERCEDES-BENZ | 123 T-Model (S123) | 300 T D (123.190) | 1977 – 1986 | 2998 | 59 | 80 |
| MERCEDES-BENZ | 123 T-Model (S123) | 300 T D | 1977 – 1986 | 3005 | 57 | 77 |
| MERCEDES-BENZ | 123 T-Model (S123) | 300 T Turbo-D (123.193) | 1977 – 1986 | 2998 | 92 | 125 |
| MERCEDES-BENZ | 123 T-Model (S123) | 300 T D (123.190) | 1977 – 1986 | 2998 | 65 | 88 |
| MERCEDES-BENZ | 123 T-Model (S123) | 200 T (123.280) | 1977 – 1986 | 1997 | 74 | 101 |
| MERCEDES-BENZ | 123 T-Model (S123) | 240 T D | 1977 – 1986 | 2399 | 48 | 65 |
| MERCEDES-BENZ | 123 T-Model (S123) | 240 T D (123.183) | 1977 – 1986 | 2399 | 53 | 72 |
| MERCEDES-BENZ | 123 T-Model (S123) | 280 TE (123.093) | 1977 – 1986 | 2746 | 136 | 185 |
| MERCEDES-BENZ | 123 T-Model (S123) | 250 T (123.086) | 1977 – 1986 | 2525 | 103 | 140 |
| MERCEDES-BENZ | 123 T-Model (S123) | 250 T (123.086) | 1977 – 1986 | 2525 | 95 | 129 |
| MERCEDES-BENZ | 123 T-Model (S123) | 230 T (123.083) | 1977 – 1986 | 2307 | 80 | 109 |
| MERCEDES-BENZ | 123 T-Model (S123) | 230 TE (123.283) | 1977 – 1986 | 2299 | 100 | 136 |
| MERCEDES-BENZ | 123 T-Model (S123) | 200 T | 1977 – 1986 | 1997 | 80 | 109 |
