Specifications
| Bolt Head Diameter (mm) | 46.0 |
| Bolt Length (mm) | 105.0 |
| Component Number 1. T 3.0 Mo | |
| Component Number 2. M3.0 IWU Cr | |
| Component Number 3. DSF 4.0 Cr | |
| Compression Height (mm) | 81.35 |
| Cylinder Bore (mm) | 128.0 |
| Length (mm) | 126.4 |
| Machined with cut-out for oil jet | |
| Net Weight (g) | 3587 |
| Packaging height (cm) | 21.00 |
| Packaging length (cm) | 15.0 |
| Packaging width (cm) | 15.00 |
| Production Number 128 L 79 | |
| Recess Depth 1 (mm) | 27.5 |
| Recess Diameter (mm) | 66.15 |
Bolt Head Diameter [mm] 46,0, Bolt Length [mm] 105,0, Component Number 1. T 3.0 Mo, Component Number 2. M3.0 IWU Cr, Component Number 3. DSF 4.0 Cr, Compression Height [mm] 81,35, Cylinder Bore [mm] 128,0, Length [mm] 126,4, Machined with cut-out for oil jet, Net Weight [g] 3587, Packaging height [cm] 21,00, Packaging length [cm] 15,0, Packaging width [cm] 15,00, Production Number 128 L 79, Recess Depth 1 [mm] 27,5, Recess Diameter [mm] 66,15, Standard Size [STD] , Supplementary Article/Info 2 with piston ring carrier, Surface Hard Anodized
