Specifications
| Bolt Head Diameter (mm) | 28.0 |
| Bolt Length (mm) | 69.0 |
| Component Number 1. R 3.0 Cr P | |
| Component Number 2. R 3.0 P | |
| Component Number 3. N 3.0 P | |
| Component Number 4. DSF5.5 Cr P | |
| Compression Height (mm) | 50.3 |
| Cylinder Bore (mm) | 85.0 |
| Length (mm) | 90.0 |
| Net Weight (g) | 790 |
| Packaging height (cm) | 14.30 |
| Packaging length (cm) | 11.6 |
| Packaging width (cm) | 11.60 |
| Production Number 85 L 52 | |
| Recess Depth 1 (mm) | 4.5 |
| Surface Tin-plated | |
Bolt Head Diameter [mm] 28,0, Bolt Length [mm] 69,0, Component Number 1. R 3.0 Cr P, Component Number 2. R 3.0 P, Component Number 3. N 3.0 P, Component Number 4. DSF5.5 Cr P, Compression Height [mm] 50,3, Cylinder Bore [mm] 85,0, Length [mm] 90,0, Net Weight [g] 790, Packaging height [cm] 14,30, Packaging length [cm] 11,6, Packaging width [cm] 11,60, Production Number 85 L 52, Recess Depth 1 [mm] 4,5, Surface Tin-plated
