Specifications
| Bolt Head Diameter (mm) | 40 |
| Bolt Length (mm) | 82.7 |
| Component Number 1. T 3.0 CrK | |
| Component Number 2. M2.385 IFU P | |
| Component Number 3. DSF4.0 Cr P | |
| Compression Height (mm) | 71.38 |
| Cylinder Bore (mm) | 102.5 |
| Length (mm) | 105.4 |
| Machined with cut-out for oil jet | |
| Net Weight (g) | 1140 |
| Packaging height (cm) | 14.30 |
| Packaging length (cm) | 11.6 |
| Packaging width (cm) | 11.60 |
| Piston Clearance (mm) | 0.11 |
| Production Number 102 L 67 | |
| Recess Depth 1 (mm) | 23.9 |
Bolt Head Diameter [mm] 40, Bolt Length [mm] 82,7, Component Number 1. T 3.0 CrK, Component Number 2. M2.385 IFU P, Component Number 3. DSF4.0 Cr P, Compression Height [mm] 71,38, Cylinder Bore [mm] 102,5, Length [mm] 105,4, Machined with cut-out for oil jet, Net Weight [g] 1140, Packaging height [cm] 14,30, Packaging length [cm] 11,6, Packaging width [cm] 11,60, Piston Clearance [mm] 0,11, Production Number 102 L 67, Recess Depth 1 [mm] 23,9, Recess Diameter [mm] 88,5, Supplementary Article/Info 2 with cooling duct, Supplementary Article/Info 2 with piston ring carrier
