Specifications
| Bolt Head Diameter (mm) | 48.00 |
| Bolt Length (mm) | 96.0 |
| Component Number 1. T 3.5 CrK | |
| Component Number 2. NM 3.0 Cr | |
| Component Number 3. DSF 5.0 Cr | |
| Compression Height (mm) | 83.1 |
| Cylinder Bore (mm) | 120.0 |
| Length (mm) | 133.1 |
| Machined with cut-out for oil jet | |
| Net Weight (g) | 1743 |
| Packaging height (cm) | 19.00 |
| Packaging length (cm) | 13.2 |
| Packaging width (cm) | 13.20 |
| Piston Clearance (mm) | 0.13 |
| Production Number 120 L 167 | |
| Recess Depth 1 (mm) | 30.15 |
Bolt Head Diameter [mm] 48,00, Bolt Length [mm] 96,0, Component Number 1. T 3.5 CrK, Component Number 2. NM 3.0 Cr, Component Number 3. DSF 5.0 Cr, Compression Height [mm] 83,1, Cylinder Bore [mm] 120,0, Length [mm] 133,1, Machined with cut-out for oil jet, Net Weight [g] 1743, Packaging height [cm] 19,00, Packaging length [cm] 13,2, Packaging width [cm] 13,20, Piston Clearance [mm] 0,13, Production Number 120 L 167, Recess Depth 1 [mm] 30,15, Recess Diameter [mm] 93, Supplementary Article/Info 2 with cooling duct, Supplementary Article/Info 2 with piston ring carrier, Surface Coated, Valve Pocket Depth 1 [mm] 1,7
