Specifications
| Bolt Head Diameter (mm) | 23.0 |
| Bolt Length (mm) | 61.0 |
| Component Number 1. M 1.2 N | |
| Component Number 2. NM 1.75 | |
| Component Number 3. DSF 3.0 Cr | |
| Compression Height (mm) | 35.9 |
| Cylinder Bore (mm) | 83.4 |
| Length (mm) | 59.9 |
| Net Weight (g) | 499 |
| Packaging height (cm) | 12.80 |
| Packaging length (cm) | 9.5 |
| Packaging width (cm) | 9.50 |
| Production Number 83 V 45 | |
| Recess Depth 1 (mm) | 2.4 |
| Recess Diameter (mm) | 60.3 |
| Valve Pocket Depth 1 (mm) | 2.48 |
Bolt Head Diameter [mm] 23,0, Bolt Length [mm] 61,0, Component Number 1. M 1.2 N, Component Number 2. NM 1.75, Component Number 3. DSF 3.0 Cr, Compression Height [mm] 35,9, Cylinder Bore [mm] 83,4, Length [mm] 59,9, Net Weight [g] 499, Packaging height [cm] 12,80, Packaging length [cm] 9,5, Packaging width [cm] 9,50, Production Number 83 V 45, Recess Depth 1 [mm] 2,4, Recess Diameter [mm] 60,3, Valve Pocket Depth 1 [mm] 2,48, Valve Pocket Depth 2 [mm] 2,66
