Specifications
| Bolt Head Diameter (mm) | 40.0 |
| Bolt Length (mm) | 80.0 |
| Component Number 1. T IW | |
| Component Number 2. M IFU | |
| Component Number 3. DSF | |
| Compression Height (mm) | 55.15 |
| Cylinder Bore (mm) | 98.0 |
| Length (mm) | 90.7 |
| Net Weight (g) | 1579 |
| Packaging height (cm) | 14.30 |
| Packaging length (cm) | 11.6 |
| Packaging width (cm) | 11.60 |
| Piston Clearance (mm) | 0.105 |
| Production Number 98 L 132 | |
| Recess Depth 1 (mm) | 17.31 |
| Recess Diameter (mm) | 61.5 |
Bolt Head Diameter [mm] 40,0, Bolt Length [mm] 80,0, Component Number 1. T IW, Component Number 2. M IFU, Component Number 3. DSF, Compression Height [mm] 55,15, Cylinder Bore [mm] 98,0, Length [mm] 90,7, Net Weight [g] 1579, Packaging height [cm] 14,30, Packaging length [cm] 11,6, Packaging width [cm] 11,60, Piston Clearance [mm] 0,105, Production Number 98 L 132, Recess Depth 1 [mm] 17,31, Recess Diameter [mm] 61,5
