Specifications

Bolt Hole Circle Ø (mm)	112
Brake Disc Thickness (mm)	30
Brake Disc Type Vented
Centering Diameter (mm)	68
Fitting Position Front Axle
Height (mm)	52
Number of Holes 5
Outer Diameter (mm)	320
Surface Coated

Bolt Hole Circle Ø [mm] 112, Brake Disc Thickness [mm] 30, Brake Disc Type Vented, Centering Diameter [mm] 68, Fitting Position Front Axle, Height [mm] 52, Number of Holes 5, Outer Diameter [mm] 320, Surface Coated
Fits: AUDI

Supplier Cross-References

HUTCHINSON594641 GSP539479 MEYLE16140300069 CORTECO49402613 BIRTH57080 3RG41683

Interchangeable Part Numbers

A.B.S.18112 A.B.S.18456 ABEC3A034ABE ASHIKA60-00-0919 ATE24.0130-0221.1 BLUE PRINTADV184368 BOSCH 0 986 479753 BOSCH0986479753 DACO Germany600225 HELLA 8DD 355117-191 HELLA8DD355117191 JAPANPARTSDI-0919 JAPKO600919 JP GROUP1163108600 MASTER-SPORT GERMANY24013002211-PCS-MS MAXGEAR19-2252MAX MAXGEAR19-2252SPORT MAXGEAR19-2252 METZGER6110716 METZGER6110765 MEYLE 183 5210022/PD MEYLE1835210022PD MINTEXMDC2263 NK2047153 PAGID55293PRO PILENGAV215 RIDEX82B0744 RIDEX82B1790 sbs18152047153 StarkSKBD-0022894 SWAG 30 944022 SWAG30944022 TEXTAR92229303 TOMEX Brakes TX72-56 TOMEX BrakesTX7256 ZIMMERMANN100.3355.20

OE Numbers — SEAT

8R0615301 8R0615301C 8R0615301D 8R0615301F

OE Numbers — VAG

8K0098301H 8R0615301E 8R0615301G

OE Numbers — VAG 8R0 615

301

Make	Model	Type / Engine	Years	CC	kW	HP
AUDI	A5 (8T3)	1.8 TFSI	2007 – 2017	1798	125	170
AUDI	A5 Convertible (8F7)	2.0 TFSI quattro	2009 – 2017	1984	155	211
