Pressure Switch, air conditioning
Part No.
120 570
·
SKU
120 570-TOPRAN
Price on request
Currently out of stock
Get notified when this part is back in stock:
Genuine & OEM parts
Nationwide delivery
Easy returns
Specifications
| Always compare old and new part (in particular OE No.) | |
| Base body material Aluminium | |
| Component Number G 395 | |
| Connector Shape oval | |
| Number of connectors for pressure switch 4 | |
| Operating Mode Electric-hydraulic | |
| Seal Material NBR (nitrile butadiene rubber) | |
| Spanner Size 24 | |
| Supplementary Article/Info 2 with seal ring | |
| Thread Pitch (mm) | 1 |
| Thread Size M 10 | |
| Vehicle Equipment for vehicles with air conditioning | |
Always compare old and new part (in particular OE No.) , Base body material Aluminium, Component Number G 395, Connector Shape oval, Number of connectors for pressure switch 4, Operating Mode Electric-hydraulic, Seal Material NBR (nitrile butadiene rubber), Spanner Size 24, Supplementary Article/Info 2 with seal ring, Thread Pitch [mm] 1, Thread Size M 10, Vehicle Equipment for vehicles with air conditioning
Fits: AUDI, CUPRA, VW
Fits: AUDI, CUPRA, VW
Interchangeable Part Numbers
OE Numbers — AUDI 4M0 959
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| AUDI | A3 Sportback (8VA, 8VF) | 1.5 TFSI | 2012 – 2021 | 1498 | 110 | 150 |
| AUDI | A3 Sportback (8VA, 8VF) | RS3 quattro | 2012 – 2021 | 2480 | 270 | 367 |
| AUDI | A3 Sportback (8VA, 8VF) | 1.6 TDI quattro | 2012 – 2021 | 1598 | 81 | 110 |
| AUDI | A3 Sportback (8VA, 8VF) | 1.4 TFSI e-tron | 2012 – 2021 | 1395 | 150 | 204 |
| AUDI | A3 Sportback (8VA, 8VF) | 1.0 TFSI | 2012 – 2021 | 999 | 85 | 115 |
| AUDI | A3 Sportback (8VA, 8VF) | S3 quattro | 2012 – 2021 | 1984 | 228 | 310 |
| AUDI | A3 Sportback (8VA, 8VF) | 2.0 TFSI quattro | 2012 – 2021 | 1984 | 140 | 190 |
| AUDI | A3 Sportback (8VA, 8VF) | 2.0 TFSI | 2012 – 2021 | 1984 | 140 | 190 |
| AUDI | A3 Sportback (8VA, 8VF) | S3 quattro | 2012 – 2021 | 1984 | 213 | 290 |
| AUDI | A3 Sportback (8VA, 8VF) | 1.6 TDI | 2012 – 2021 | 1598 | 85 | 115 |
| AUDI | A3 Sportback (8VA, 8VF) | RS3 quattro | 2012 – 2021 | 2480 | 294 | 400 |
| AUDI | A3 Sportback (8VA, 8VF) | 2.0 45 TFSI | 2012 – 2021 | 1984 | 162 | 220 |
| AUDI | A3 Sportback (8VA, 8VF) | 30 TFSI | 2012 – 2021 | 999 | 85 | 116 |
| AUDI | A3 Sportback (8VA, 8VF) | 35 TFSI | 2012 – 2021 | 1498 | 110 | 150 |
| AUDI | A3 Sportback (8VA, 8VF) | 30 TDI | 2012 – 2021 | 1598 | 85 | 115 |
| AUDI | A3 Sportback (8VA, 8VF) | 30 g-tron | 2012 – 2021 | 1498 | 96 | 131 |
| AUDI | A3 Sportback (8VA, 8VF) | 40 TFSI | 2012 – 2021 | 1984 | 140 | 190 |
| AUDI | A3 Sportback (8VA, 8VF) | 35 TDI | 2012 – 2021 | 1968 | 110 | 150 |
| AUDI | A3 Sportback (8VA, 8VF) | 40 TFSI quattro | 2012 – 2021 | 1984 | 140 | 190 |
| AUDI | A3 Sportback (8VA, 8VF) | 40 TDI quattro | 2012 – 2021 | 1968 | 135 | 184 |
| AUDI | A3 Sportback (8VA, 8VF) | 40 e-tron | 2012 – 2021 | 1395 | 150 | 204 |
| AUDI | A3 Sportback (8VA, 8VF) | 1.8 40 TFSI | 2012 – 2021 | 1798 | 132 | 180 |
| AUDI | A3 Sportback (8VA, 8VF) | 1.2 TFSI | 2012 – 2021 | 1197 | 77 | 105 |
| AUDI | A3 Sportback (8VA, 8VF) | 1.4 TFSI | 2012 – 2021 | 1395 | 90 | 122 |
| AUDI | A3 Sportback (8VA, 8VF) | 2.0 TDI | 2012 – 2021 | 1968 | 110 | 150 |
| AUDI | A3 Sportback (8VA, 8VF) | 2.0 TDI quattro | 2012 – 2021 | 1968 | 135 | 184 |
| AUDI | A3 Sportback (8VA, 8VF) | 2.0 TDI | 2012 – 2021 | 1968 | 105 | 143 |
| AUDI | A3 Sportback (8VA, 8VF) | 1.8 TFSI | 2012 – 2021 | 1798 | 132 | 180 |
| AUDI | A3 Sportback (8VA, 8VF) | 1.6 TDI | 2012 – 2021 | 1598 | 77 | 105 |
| AUDI | A3 Sportback (8VA, 8VF) | 1.4 TFSI | 2012 – 2021 | 1395 | 103 | 140 |
| AUDI | A3 Sportback (8VA, 8VF) | 2.0 TDI quattro | 2012 – 2021 | 1968 | 110 | 150 |
| AUDI | A3 Sportback (8VA, 8VF) | S3 quattro | 2012 – 2021 | 1984 | 221 | 300 |
| AUDI | A3 Sportback (8VA, 8VF) | 1.8 TFSI quattro | 2012 – 2021 | 1798 | 132 | 180 |
| AUDI | A3 Sportback (8VA, 8VF) | 2.0 TDI | 2012 – 2021 | 1968 | 81 | 110 |
| AUDI | A3 Sportback (8VA, 8VF) | 2.0 TDI | 2012 – 2021 | 1968 | 135 | 184 |
| AUDI | A3 Sportback (8VA, 8VF) | 2.0 TDI | 2012 – 2021 | 1968 | 100 | 136 |
| AUDI | A3 Sportback (8VA, 8VF) | S3 quattro | 2012 – 2021 | 1984 | 206 | 280 |
| AUDI | A3 Sportback (8VA, 8VF) | 1.6 TDI | 2012 – 2021 | 1598 | 81 | 110 |
| AUDI | A3 Sportback (8VA, 8VF) | 1.4 TFSI g-tron | 2012 – 2021 | 1395 | 81 | 110 |
| AUDI | A3 Sportback (8VA, 8VF) | 1.2 TFSI | 2012 – 2021 | 1197 | 81 | 110 |
| AUDI | A3 Sportback (8VA, 8VF) | 1.4 TFSI | 2012 – 2021 | 1395 | 92 | 125 |
| AUDI | A3 Sportback (8VA, 8VF) | 1.4 TSI | 2012 – 2021 | 1395 | 110 | 150 |
| AUDI | A3 Sportback (8VA, 8VF) | S3 quattro | 2012 – 2021 | 1984 | 210 | 286 |
