Specifications
| Brake Caliper Type Brake Caliper (2 pistons) | |
| Brake Caliper Type Floating Caliper | |
| Brake Disc Type Vented | |
| Fitting Position Front Axle Left | |
| Fitting Position in front of axle, for brake disc diameter (mm) | 304 |
| Manufacturer Restriction LUCAS | |
| Material Cast Iron | |
| Net weight (kg) | 13.2. paired article number 2199141 |
| Piston Diameter (mm) | 60 |
Brake Caliper Type Brake Caliper (2 pistons), Brake Caliper Type Floating Caliper, Brake Disc Type Vented, Fitting Position Front Axle Left, Fitting Position in front of axle, for brake disc diameter [mm] 304, Manufacturer Restriction LUCAS, Material Cast Iron, Net weight [kg] 13,2, paired article number 2199141, Piston Diameter [mm] 60
Fits: IVECO, MERCEDES-BENZ
Fits: IVECO, MERCEDES-BENZ
Interchangeable Part Numbers
OE Numbers — IVECO
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 814 D (670.312, 670.313) | 1986 – 2011 | 3972 | 103 | 140 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 611 D (668.001, 668.002, 668.003) | 1986 – 2011 | 3972 | 77 | 105 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 611 DK (668.041, 668.042) | 1986 – 2011 | 3972 | 77 | 105 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 809 D (670.001, 670.002, 670.003) | 1986 – 2011 | 3972 | 63 | 86 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 811 D (670.303) | 1986 – 2011 | 3972 | 77 | 105 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 510 (667.001, 667.002) | 1986 – 2011 | 2299 | 77 | 105 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 609 D (668.001, 668.002, 668.003) | 1986 – 2011 | 3972 | 66 | 90 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 609 DK (668.041, 668.042) | 1986 – 2011 | 3972 | 66 | 90 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 709 D (669.000, 669.001, 669.002, 669.003, 669.041) | 1986 – 2011 | 3972 | 66 | 90 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 709 DK (669.041, 669.042) | 1986 – 2011 | 3972 | 66 | 90 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 711 D (669.301, 669.302, 669.303) | 1986 – 2011 | 3972 | 85 | 115 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 809 DK (670.041, 670.042) | 1986 – 2011 | 3972 | 66 | 90 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 811 DK (670.341, 670.342) | 1986 – 2011 | 3972 | 85 | 115 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 507 D (667.301, 667.302, 667.341, 667.342) | 1986 – 2011 | 2399 | 53 | 72 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 814 DA 4x4 (670.411, 670.412) | 1986 – 2011 | 3972 | 100 | 136 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 809 D (670.001, 670.002, 670.003) | 1986 – 2011 | 3972 | 66 | 90 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 811 D (670.302, 670.303) | 1986 – 2011 | 3972 | 85 | 116 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 709 D (669.001, 669.002, 669.003, 669.041, 669.000) | 1986 – 2011 | 3972 | 63 | 86 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 710 (688.156, 688.157) | 1986 – 2011 | 3972 | 81 | 110 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 710 (688.156, 688.157) | 1986 – 2011 | 3972 | 77 | 105 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 710 (688.158, 688.159) | 1986 – 2011 | 3972 | 85 | 116 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 712 (688.118) | 1986 – 2011 | 3972 | 85 | 116 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 912 (688.123) | 1986 – 2011 | 3972 | 85 | 116 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 914 (688.133, 688.138) | 1986 – 2011 | 3972 | 100 | 136 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 709 (688.102, 688.103) | 1986 – 2011 | 3972 | 66 | 90 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 507 DK (667.341, 667.342) | 1986 – 2011 | 2399 | 53 | 72 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 814 D (670.312, 670.313) | 1986 – 2011 | 3972 | 100 | 136 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 809 DK (670.041, 670.042) | 1986 – 2011 | 3972 | 63 | 86 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 508 D (667.301, 667.302, 667.341, 667.342) | 1986 – 2011 | 2299 | 58 | 79 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 714 D (669.301, 669.302, 669.303) | 1986 – 2011 | 3972 | 103 | 140 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 510 (667.001, 667.002) | 1986 – 2011 | 2299 | 70 | 95 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 709 DK (669.041, 669.042) | 1986 – 2011 | 3972 | 63 | 86 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 609 D (668.001, 668.002, 668.003) | 1986 – 2011 | 3972 | 63 | 86 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 609 DK (668.041, 668.042) | 1986 – 2011 | 3972 | 63 | 86 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 814 DA 4x4 (670.411, 670.412) | 1986 – 2011 | 3972 | 100 | 136 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 609 D (668.001, 668.002, 668.003) | 1986 – 2011 | 3972 | 77 | 105 |
| MERCEDES-BENZ | T2/LN1 Platform/Chassis | 711 D (669.301, 669.302, 669.303) | 1986 – 2011 | 3972 | 77 | 105 |
| MERCEDES-BENZ | T2/LN1 Van | 714 D (669.361, 669.362, 669.363) | 1986 – 1994 | 3972 | 103 | 140 |
| MERCEDES-BENZ | T2/LN1 Van | 711 D (669.361, 669.362, 669.363) | 1986 – 1994 | 3972 | 77 | 105 |
| MERCEDES-BENZ | T2/LN1 Van | 809 D (670.061, 670.062, 670.063) | 1986 – 1994 | 3972 | 66 | 90 |
| MERCEDES-BENZ | T2/LN1 Van | 709 D (669.061, 669.062, 669.063) | 1986 – 1994 | 3972 | 66 | 90 |
| MERCEDES-BENZ | T2/LN1 Van | 711 D (669.361, 669.362, 669.363) | 1986 – 1994 | 3972 | 85 | 115 |
| MERCEDES-BENZ | T2/LN1 Van | 811 D (670.362, 670.363) | 1986 – 1994 | 3972 | 85 | 115 |
| MERCEDES-BENZ | T2/LN1 Van | 814 D (670.364, 670.365, 670.366) | 1986 – 1994 | 3972 | 103 | 140 |
| MERCEDES-BENZ | T2/LN1 Van | 709 D (669.061, 669.062, 669.063) | 1986 – 1994 | 3972 | 63 | 86 |
| MERCEDES-BENZ | T2/LN1 Van | 609 D (668.061, 668.062, 668.063) | 1986 – 1994 | 3972 | 77 | 105 |
| MERCEDES-BENZ | T2/LN1 Van | 609 D (668.061, 668.062, 668.063) | 1986 – 1994 | 3972 | 63 | 86 |
| MERCEDES-BENZ | T2/LN1 Van | 510 (667.061, 667.062) | 1986 – 1994 | 2299 | 70 | 95 |
| MERCEDES-BENZ | T2/LN1 Van | 508 D (667.361, 667.362) | 1986 – 1994 | 2299 | 58 | 79 |
| MERCEDES-BENZ | T2/LN1 Van | 507 D (667.361, 667.362) | 1986 – 1994 | 2399 | 53 | 72 |
| MERCEDES-BENZ | T2/LN1 Van | 609 D (668.061, 668.062, 668.063) | 1986 – 1994 | 3972 | 66 | 90 |
| MERCEDES-BENZ | T2/LN1 Van | 814 DA 4x4 (670.464, 670.465) | 1986 – 1994 | 3972 | 100 | 136 |
| MERCEDES-BENZ | T2/LN1 Van | 611 D (668.061, 668.062, 668.063) | 1986 – 1994 | 3972 | 77 | 105 |
| MERCEDES-BENZ | T2/LN1 Van | 814 D (670.364, 670.365, 670.366) | 1986 – 1994 | 3972 | 100 | 136 |
| MERCEDES-BENZ | T2/LN1 Van | 809 D (670.061, 670.062, 670.063) | 1986 – 1994 | 3972 | 63 | 86 |
| MERCEDES-BENZ | T2/LN1 Van | 811 D (670.362, 670.363) | 1986 – 1994 | 3972 | 77 | 105 |
| MERCEDES-BENZ | T2/LN1 Van | 510 (667.061, 667.062) | 1986 – 1994 | 2299 | 77 | 105 |
| MERCEDES-BENZ | VARIO Bus (B670) | O 815 (670.373, 670.374) | 1996 – present | 4249 | 112 | 152 |
| MERCEDES-BENZ | VARIO Bus (B670) | O 814 (670.373, 670.374) | 1996 – present | 4249 | 100 | 136 |
| MERCEDES-BENZ | VARIO Bus (B670) | O 812 (670.373, 670.674) | 1996 – present | 2874 | 90 | 122 |
| MERCEDES-BENZ | VARIO Bus (B670) | O 810 (670.373, 670.374) | 1996 – present | 4249 | 75 | 102 |
| MERCEDES-BENZ | VARIO Bus (B670) | O 815 (670.373, 670.374) | 1996 – present | 4249 | 110 | 150 |
| MERCEDES-BENZ | VARIO Bus (B670) | O 818 D (670.373, 670.374) | 1996 – present | 4249 | 130 | 177 |
| MERCEDES-BENZ | VARIO Bus (B670) | O 816 D (670.373, 670.374) | 1996 – present | 4249 | 115 | 156 |
| MERCEDES-BENZ | VARIO Bus (B670) | O 813 (670.373, 670.374) | 1996 – present | 4249 | 95 | 129 |
| MERCEDES-BENZ | VARIO Van (B667, B670, B668) | 815 DA, 816 DA 4x4 (669.599, 670.451, 670.452, 670.453) | 1996 – present | 4249 | 115 | 156 |
| MERCEDES-BENZ | VARIO Van (B667, B670, B668) | 512 D (667.351, 667.352, 667.353) | 1996 – present | 2874 | 90 | 122 |
| MERCEDES-BENZ | VARIO Van (B667, B670, B668) | 612 D (668.351, 668.352, 668.353) | 1996 – present | 2874 | 90 | 122 |
| MERCEDES-BENZ | VARIO Van (B667, B670, B668) | 613 D, 614 D (668.351, 668.352, 668.353) | 1996 – present | 4249 | 95 | 129 |
| MERCEDES-BENZ | VARIO Van (B667, B670, B668) | 615 D, 616 D (668.351, 668.352, 668.353) | 1996 – present | 4249 | 115 | 156 |
| MERCEDES-BENZ | VARIO Van (B667, B670, B668) | 812 D (670.351, 670.352, 670.353) | 1996 – present | 2874 | 90 | 122 |
| MERCEDES-BENZ | VARIO Van (B667, B670, B668) | 615 D, 616 D (668.351, 668.352, 668.353) | 1996 – present | 4249 | 112 | 152 |
| MERCEDES-BENZ | VARIO Van (B667, B670, B668) | 618 D | 1996 – present | 4249 | 130 | 177 |
| MERCEDES-BENZ | VARIO Van (B667, B670, B668) | 813 DA, 814 DA 4x4 (669.599, 670.451, 670.452, 670.453) | 1996 – present | 4249 | 100 | 136 |
| MERCEDES-BENZ | VARIO Van (B667, B670, B668) | 815 D, 816 D (670.351, 670.352, 670.353) | 1996 – present | 4249 | 115 | 156 |
| MERCEDES-BENZ | VARIO Van (B667, B670, B668) | 813 D, 814 D (670.351, 670.352, 670.353) | 1996 – present | 4249 | 100 | 136 |
| MERCEDES-BENZ | VARIO Van (B667, B670, B668) | 613 D, 614 D (668.351, 668.352, 668.353) | 1996 – present | 4249 | 100 | 136 |
| MERCEDES-BENZ | VARIO Van (B667, B670, B668) | 813 D, 814 D (670.351, 670.352, 670.353) | 1996 – present | 4249 | 95 | 129 |
| MERCEDES-BENZ | VARIO Van (B667, B670, B668) | 815 D, 816 D (670.351, 670.352, 670.353) | 1996 – present | 4249 | 112 | 152 |
| MERCEDES-BENZ | VARIO Van (B667, B670, B668) | 813 DA, 814 DA 4x4 (669.599, 670.451, 670.452, 670.453) | 1996 – present | 4249 | 95 | 129 |
| MERCEDES-BENZ | VARIO Van (B667, B670, B668) | 815 DA, 816 DA 4x4 (669.599, 670.451, 670.452, 670.453) | 1996 – present | 4249 | 112 | 152 |
| MERCEDES-BENZ | VARIO Van (B667, B670, B668) | 818 D (670.351, 670.352, 670.353) | 1996 – present | 4249 | 130 | 177 |
