Specifications
| Bolt Head Diameter (mm) | 55 |
| Bolt Length (mm) | 99 |
| Component Number 1. T 3.50 CrK | |
| Component Number 2. M 2.50 Cr P | |
| Component Number 3. DSF 3.5 Cr | |
| Compression Height (mm) | 78.5 |
| Cylinder Bore (mm) | 132 |
| Length (mm) | 125 |
| Net Weight (g) | 3934 |
| Packaging height (cm) | 21.00 |
| Packaging length (cm) | 15.0 |
| Packaging width (cm) | 15.00 |
| Production Number 132 L 20 | |
| Recess Depth 1 (mm) | 25.3 |
| Recess Diameter (mm) | 86.2 |
| Supplementary Article/Info 2 with piston ring carrier | |
Bolt Head Diameter [mm] 55, Bolt Length [mm] 99, Component Number 1. T 3.50 CrK, Component Number 2. M 2.50 Cr P, Component Number 3. DSF 3.5 Cr, Compression Height [mm] 78,5, Cylinder Bore [mm] 132, Length [mm] 125, Net Weight [g] 3934, Packaging height [cm] 21,00, Packaging length [cm] 15,0, Packaging width [cm] 15,00, Production Number 132 L 20, Recess Depth 1 [mm] 25,3, Recess Diameter [mm] 86,2, Supplementary Article/Info 2 with piston ring carrier, Supplementary Article/Info 2 without cooling duct, Surface Phosphated and graphite-coated
