Specifications
| Bolt Head Diameter (mm) | 46 |
| Bolt Length (mm) | 105 |
| Component Number 1. T 3 IF CrK | |
| Component Number 2. M 3 Cr | |
| Component Number 3. DSF 4 CrK | |
| Compression Height (mm) | 80.7 |
| Cylinder Bore (mm) | 130 |
| Length (mm) | 125.7 |
| Net Weight (g) | 3660 |
| Packaging height (cm) | 21.00 |
| Packaging length (cm) | 15.0 |
| Packaging width (cm) | 15.00 |
| Recess Depth 1 (mm) | 32 |
| Recess Diameter (mm) | 72.3 |
| Supplementary Article/Info 2 with piston ring carrier | |
Bolt Head Diameter [mm] 46, Bolt Length [mm] 105, Component Number 1. T 3 IF CrK, Component Number 2. M 3 Cr, Component Number 3. DSF 4 CrK, Compression Height [mm] 80,7, Cylinder Bore [mm] 130, Length [mm] 125,7, Net Weight [g] 3660, Packaging height [cm] 21,00, Packaging length [cm] 15,0, Packaging width [cm] 15,00, Recess Depth 1 [mm] 32, Recess Diameter [mm] 72,3, Supplementary Article/Info 2 with piston ring carrier
