Specifications
| Bolt Head Diameter (mm) | 46.0 |
| Bolt Length (mm) | 105.0 |
| Component Number 1. T 3.5 Cr | |
| Component Number 2. M 3.0 P | |
| Component Number 3. M 3.0 P | |
| Component Number 4. DSF 5.0 Cr | |
| Compression Height (mm) | 81.3 |
| Cylinder Bore (mm) | 125.0 |
| Length (mm) | 130.3 |
| Net Weight (g) | 3150 |
| Net Weight (g) | 3404 |
| Packaging height (cm) | 21.00 |
| Packaging length (cm) | 15.0 |
| Packaging width (cm) | 15.00 |
| Production Number 125 L 72 | |
| Recess Depth 1 (mm) | 37.0 |
Bolt Head Diameter [mm] 46,0, Bolt Length [mm] 105,0, Component Number 1. T 3.5 Cr, Component Number 2. M 3.0 P, Component Number 3. M 3.0 P, Component Number 4. DSF 5.0 Cr, Compression Height [mm] 81,3, Cylinder Bore [mm] 125,0, Length [mm] 130,3, Net Weight [g] 3150, Net Weight [g] 3404, Packaging height [cm] 21,00, Packaging length [cm] 15,0, Packaging width [cm] 15,00, Production Number 125 L 72, Recess Depth 1 [mm] 37,0, Recess Diameter [mm] 50,0, Standard Size [STD] , Supplementary Article/Info 2 with piston ring carrier, Supplementary Article/Info 2 without cooling duct, Surface Hard Anodized, Valve Pocket Depth 1 [mm] 1,2
