Specifications
| Bolt Head Diameter (mm) | 46.0 |
| Bolt Length (mm) | 105.0 |
| Component Number 1. T3.0 IF CrK | |
| Component Number 2. M 3.0 Cr | |
| Component Number 3. DSF 4.0 CrK | |
| Compression Height (mm) | 80.7 |
| Cylinder Bore (mm) | 130.0 |
| Length (mm) | 125.7 |
| Machined with cut-out for oil jet | |
| Net Weight (g) | 3520 |
| Packaging height (cm) | 21.00 |
| Packaging length (cm) | 15.0 |
| Packaging width (cm) | 15.00 |
| Production Number 130 L 128 | |
| Recess Depth 1 (mm) | 25.07 |
| Recess Diameter (mm) | 92.96 |
Bolt Head Diameter [mm] 46,0, Bolt Length [mm] 105,0, Component Number 1. T3.0 IF CrK, Component Number 2. M 3.0 Cr, Component Number 3. DSF 4.0 CrK, Compression Height [mm] 80,7, Cylinder Bore [mm] 130,0, Length [mm] 125,7, Machined with cut-out for oil jet, Net Weight [g] 3520, Packaging height [cm] 21,00, Packaging length [cm] 15,0, Packaging width [cm] 15,00, Production Number 130 L 128, Recess Depth 1 [mm] 25,07, Recess Diameter [mm] 92,96, Supplementary Article/Info 2 with piston ring carrier, Surface Coated
