Specifications
| Bolt Hole Circle Ø (mm) | 88.5 |
| Bore Diameter (mm) | 12.2 |
| Brake Disc Thickness (mm) | 12.7 |
| Brake Disc Type solid | |
| Centering Diameter (mm) | 69.5 |
| Height (mm) | 67.5 |
| Inner Diameter (mm) | 109.5 |
| MAPP code available | |
| Minimum thickness (mm) | 11.1 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 253.0 |
| Test Mark E1 90R-02C0165/0856 | |
Bolt Hole Circle Ø [mm] 88,5, Bore Diameter [mm] 12,2, Brake Disc Thickness [mm] 12,7, Brake Disc Type solid, Centering Diameter [mm] 69,5, Height [mm] 67,5, Inner Diameter [mm] 109,5, MAPP code available , Minimum thickness [mm] 11,1, Number of Holes 5, Outer Diameter [mm] 253,0, Test Mark E1 90R-02C0165/0856
Fits: MERCEDES-BENZ
Fits: MERCEDES-BENZ
Interchangeable Part Numbers
OE Numbers — MERCEDES-BENZ
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| MERCEDES-BENZ | COUPE (W111, W112) | 250 C | 1961 – 1971 | 2778 | 112 | 152 |
| MERCEDES-BENZ | COUPE (W111, W112) | 280 SE 3.5 (111.026) | 1961 – 1971 | 3499 | 147 | 200 |
| MERCEDES-BENZ | COUPE (W111, W112) | 280 SE (111.024) | 1961 – 1971 | 2778 | 118 | 160 |
| MERCEDES-BENZ | COUPE (W111, W112) | 250 SE (111.021) | 1961 – 1971 | 2496 | 110 | 150 |
| MERCEDES-BENZ | COUPE (W111, W112) | 220 SEB (111.021) | 1961 – 1971 | 2196 | 88 | 120 |
| MERCEDES-BENZ | HECKFLOSSE (W110) | 200 (110.010) | 1959 – 1968 | 1988 | 61 | 83 |
| MERCEDES-BENZ | HECKFLOSSE (W110) | 220 S | 1959 – 1968 | 2196 | 89 | 121 |
| MERCEDES-BENZ | HECKFLOSSE (W110) | 220 | 1959 – 1968 | 2196 | 78 | 106 |
| MERCEDES-BENZ | HECKFLOSSE (W110) | 200 D | 1959 – 1968 | 1988 | 45 | 61 |
| MERCEDES-BENZ | HECKFLOSSE (W110) | 190 DC | 1959 – 1968 | 1983 | 45 | 61 |
| MERCEDES-BENZ | HECKFLOSSE (W110) | 200 D (110.110) | 1959 – 1968 | 1971 | 40 | 55 |
| MERCEDES-BENZ | HECKFLOSSE (W110) | 190 C (110.010) | 1959 – 1968 | 1884 | 59 | 80 |
| MERCEDES-BENZ | HECKFLOSSE (W110) | 230 | 1959 – 1968 | 2281 | 88 | 120 |
| MERCEDES-BENZ | HECKFLOSSE (W110) | 230 (110.011) | 1959 – 1968 | 2281 | 77 | 105 |
| MERCEDES-BENZ | HECKFLOSSE (W110) | 200 | 1959 – 1968 | 1988 | 70 | 95 |
| MERCEDES-BENZ | HECKFLOSSE (W110) | 190 DC (110.110) | 1959 – 1968 | 1988 | 40 | 54 |
| MERCEDES-BENZ | HECKFLOSSE (W111, W112) | 220 SEB (111.014) | 1959 – 1968 | 2180 | 88 | 120 |
| MERCEDES-BENZ | HECKFLOSSE (W111, W112) | 300 SEL | 1959 – 1968 | 2778 | 134 | 182 |
| MERCEDES-BENZ | HECKFLOSSE (W111, W112) | 300 SEL | 1959 – 1968 | 2778 | 145 | 197 |
| MERCEDES-BENZ | HECKFLOSSE (W111, W112) | 300 SE | 1959 – 1968 | 2778 | 138 | 188 |
| MERCEDES-BENZ | HECKFLOSSE (W111, W112) | 220 SE | 1959 – 1968 | 2196 | 100 | 136 |
| MERCEDES-BENZ | HECKFLOSSE (W111, W112) | 220 SE | 1959 – 1968 | 2196 | 90 | 122 |
| MERCEDES-BENZ | HECKFLOSSE (W111, W112) | 220 B (111.010) | 1959 – 1968 | 2195 | 70 | 95 |
| MERCEDES-BENZ | HECKFLOSSE (W111, W112) | 220 SB (111.012) | 1959 – 1968 | 2195 | 81 | 110 |
| MERCEDES-BENZ | HECKFLOSSE (W111, W112) | 190 C | 1959 – 1968 | 1901 | 67 | 91 |
| MERCEDES-BENZ | HECKFLOSSE (W111, W112) | 300 SE (112.021, 112.023) | 1959 – 1968 | 2996 | 125 | 170 |
| MERCEDES-BENZ | HECKFLOSSE (W111, W112) | 300 SE (112.014, 112.015) | 1959 – 1968 | 2996 | 118 | 160 |
| MERCEDES-BENZ | HECKFLOSSE (W111, W112) | 230 S (111.010) | 1959 – 1968 | 2281 | 88 | 120 |
| MERCEDES-BENZ | PAGODE (W113) | 280 SL (113.044) | 1963 – 1971 | 2778 | 134 | 182 |
| MERCEDES-BENZ | PAGODE (W113) | 280 SL (113.044) | 1963 – 1971 | 2780 | 125 | 170 |
| MERCEDES-BENZ | PAGODE (W113) | 250 SL (113.043) | 1963 – 1971 | 2496 | 110 | 150 |
| MERCEDES-BENZ | PAGODE (W113) | 230 SL (113.042) | 1963 – 1971 | 2306 | 110 | 150 |
