Specifications
| Bolt Hole Circle Ø (mm) | 112.0 |
| Bore Diameter (mm) | 13.0 |
| Brake Disc Thickness (mm) | 32.0 |
| Brake Disc Type perforated/vented | |
| Centering Diameter (mm) | 67.0 |
| Height (mm) | 51.5 |
| Inner Diameter (mm) | 154.0 |
| Machining Alloyed/High-carbon | |
| MAPP code available | |
| Minimum thickness (mm) | 30.0 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 334.0 |
| Surface Coated | |
| Test Mark E1 90R-02C0640/1205 | |
Bolt Hole Circle Ø [mm] 112,0, Bore Diameter [mm] 13,0, Brake Disc Thickness [mm] 32,0, Brake Disc Type perforated/vented, Centering Diameter [mm] 67,0, Height [mm] 51,5, Inner Diameter [mm] 154,0, Machining Alloyed/High-carbon, MAPP code available , Minimum thickness [mm] 30,0, Number of Holes 5, Outer Diameter [mm] 334,0, Surface Coated, Test Mark E1 90R-02C0640/1205
Fits: MERCEDES-BENZ
Fits: MERCEDES-BENZ
Interchangeable Part Numbers
OE Numbers — MERCEDES-BENZ
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| MERCEDES-BENZ | SL (R129) | 280 (129.059) | 1989 – 2004 | 2799 | 150 | 204 |
| MERCEDES-BENZ | SL (R129) | SL 320 (129.063) | 1989 – 2004 | 3199 | 162 | 220 |
| MERCEDES-BENZ | SL (R129) | 300 SL | 1989 – 2004 | 2962 | 162 | 220 |
| MERCEDES-BENZ | SL (R129) | 55 AMG | 1989 – 2004 | 5439 | 350 | 476 |
| MERCEDES-BENZ | SL (R129) | 600 SL (129.076) | 1989 – 2004 | 5987 | 300 | 408 |
| MERCEDES-BENZ | SL (R129) | SL 73 AMG (129.076) | 1989 – 2004 | 7291 | 386 | 525 |
| MERCEDES-BENZ | SL (R129) | 55 AMG | 1989 – 2004 | 5439 | 260 | 354 |
| MERCEDES-BENZ | SL (R129) | 500 (129.068) | 1989 – 2004 | 4966 | 225 | 306 |
| MERCEDES-BENZ | SL (R129) | 320 (129.064) | 1989 – 2004 | 3199 | 165 | 224 |
| MERCEDES-BENZ | SL (R129) | 280 (129.058) | 1989 – 2004 | 2799 | 142 | 193 |
| MERCEDES-BENZ | SL (R129) | 60 AMG (129.067) | 1989 – 2004 | 5956 | 280 | 381 |
| MERCEDES-BENZ | SL (R129) | 600 (129.076) | 1989 – 2004 | 5987 | 290 | 394 |
| MERCEDES-BENZ | SL (R129) | 500 SL (129.066) | 1989 – 2004 | 4973 | 240 | 326 |
| MERCEDES-BENZ | SL (R129) | 500 (129.067) | 1989 – 2004 | 4973 | 235 | 320 |
| MERCEDES-BENZ | SL (R129) | 320 (129.063) | 1989 – 2004 | 3199 | 170 | 231 |
| MERCEDES-BENZ | SL (R129) | 300 SL-24 (129.061) | 1989 – 2004 | 2960 | 170 | 231 |
| MERCEDES-BENZ | SL (R129) | 300 SL (129.060) | 1989 – 2004 | 2960 | 140 | 190 |
