Specifications
| Core Depth (mm) | 34 |
| Core Length (mm) | 341 |
| Core Width (mm) | 322 |
| Heating/Cooling for vehicles without oil cooler | |
| Heating/Cooling with expansion tank | |
| Inlet Ø (mm) | 36 |
| Material Aluminium | |
| Outlet Ø (mm) | 36 |
| Supplementary Article/Info 2 with coolant regulator | |
| Weight (kg) | 2.756 |
Core Depth [mm] 34, Core Length [mm] 341, Core Width [mm] 322, Heating/Cooling for vehicles without oil cooler, Heating/Cooling with expansion tank, Inlet Ø [mm] 36, Material Aluminium, Outlet Ø [mm] 36, Supplementary Article/Info 2 with coolant regulator, Weight [kg] 2,756
