Specifications
| Bolt Hole Circle Ø (mm) | 160 |
| Brake Disc Thickness (mm) | 16 |
| Brake Disc Type solid | |
| Centering Diameter (mm) | 96.1 |
| Height (mm) | 68.9 |
| Minimum thickness (mm) | 13 |
| Net weight (kg) | 10.23 |
| Outer Diameter (mm) | 308 |
| Rim Hole Number 5 | |
| Supplementary Article/Info 2 with ABS sensor ring | |
| Surface Coated | |
Bolt Hole Circle Ø [mm] 160, Brake Disc Thickness [mm] 16, Brake Disc Type solid, Centering Diameter [mm] 96,1, Height [mm] 68,9, Minimum thickness [mm] 13, Net weight [kg] 10,23, Outer Diameter [mm] 308, Rim Hole Number 5, Supplementary Article/Info 2 with ABS sensor ring, Surface Coated
