Specifications
| Bolt Head Diameter (mm) | 35.0 |
| Bolt Length (mm) | 77.0 |
| Component Number 1. R 3.00 Cr | |
| Component Number 2. M 3.00 P | |
| Component Number 3. M 3.00 P | |
| Component Number 4. G 5 P | |
| Component Number 5. G 5.00 P | |
| Compression Height (mm) | 66.0 |
| Cylinder Bore (mm) | 95.0 |
| Length (mm) | 114.0 |
| Net Weight (g) | 1300 |
| Packaging height (cm) | 14.30 |
| Packaging length (cm) | 11.6 |
| Packaging width (cm) | 11.60 |
| Piston Clearance (mm) | 0.092 |
| Production Number 95 L 114 | |
Bolt Head Diameter [mm] 35,0, Bolt Length [mm] 77,0, Component Number 1. R 3.00 Cr, Component Number 2. M 3.00 P, Component Number 3. M 3.00 P, Component Number 4. G 5 P, Component Number 5. G 5.00 P, Compression Height [mm] 66,0, Cylinder Bore [mm] 95,0, Length [mm] 114,0, Net Weight [g] 1300, Packaging height [cm] 14,30, Packaging length [cm] 11,6, Packaging width [cm] 11,60, Piston Clearance [mm] 0,092, Production Number 95 L 114, Recess Depth 1 [mm] 18,4, Recess Diameter [mm] 48,0
