Specifications
| ABS-Ring Diameter (mm) | 81 |
| Bolt Hole Circle Ø (mm) | 104 |
| Bore Diameter (mm) | 10 |
| Diameter 2 (mm) | 84 |
| External Toothing wheel side 38 | |
| Length (mm) | 621 |
| Number of bores 6 | |
| Number of Teeth | |
| ABS ring 45 | |
| Sealing Ring Diameter (mm) | 59 |
| Thread Size M16x1.5 | |
| Transmission-sided joint diameter (mm) | 85 |
| Wheel-sided joint diameter (mm) | 100 |
ABS-Ring Diameter [mm] 81, Bolt Hole Circle Ø [mm] 104, Bore Diameter [mm] 10, Diameter 2 [mm] 84, External Toothing wheel side 38, Length [mm] 621, Number of bores 6, Number of Teeth, ABS ring 45, Sealing Ring Diameter [mm] 59, Thread Size M16x1.5, Transmission-sided joint diameter [mm] 85, Wheel-sided joint diameter [mm] 100
