Specifications
| Bolt Hole Circle Ø (mm) | 94 |
| Bore Diameter (mm) | 10 |
| Diameter 2 (mm) | 108 |
| External Toothing wheel side 30 | |
| Length (mm) | 740 |
| Number of bores 6 | |
| Sealing Ring Diameter (mm) | 64 |
| Thread Size M24x1.5 | |
| Transmission-sided joint diameter (mm) | 109 |
| Wheel-sided joint diameter (mm) | 98 |
Bolt Hole Circle Ø [mm] 94, Bore Diameter [mm] 10, Diameter 2 [mm] 108, External Toothing wheel side 30, Length [mm] 740, Number of bores 6, Sealing Ring Diameter [mm] 64, Thread Size M24x1.5, Transmission-sided joint diameter [mm] 109, Wheel-sided joint diameter [mm] 98
Fits: AUDI
Fits: AUDI
Interchangeable Part Numbers
OE Numbers — AUDI
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| AUDI | Q7 (4LB) | 3.0 TDI quattro | 2006 – 2016 | 2967 | 180 | 245 |
| AUDI | Q7 (4LB) | 3.0 TDI quattro | 2006 – 2016 | 2967 | 150 | 204 |
| AUDI | Q7 (4LB) | 3.0 TFSI quattro | 2006 – 2016 | 2995 | 245 | 333 |
| AUDI | Q7 (4LB) | 3.0 TFSI quattro | 2006 – 2016 | 2995 | 200 | 272 |
| AUDI | Q7 (4LB) | 4.2 TDI quattro | 2006 – 2016 | 4134 | 250 | 340 |
| AUDI | Q7 (4LB) | 6.0 TDI quattro | 2006 – 2016 | 5934 | 368 | 500 |
| AUDI | Q7 (4LB) | 3.0 TDI quattro | 2006 – 2016 | 2967 | 176 | 240 |
| AUDI | Q7 (4LB) | 3.0 TDI quattro | 2006 – 2016 | 2967 | 155 | 211 |
| AUDI | Q7 (4LB) | 3.6 FSI quattro | 2006 – 2016 | 3597 | 206 | 280 |
| AUDI | Q7 (4LB) | 3.0 TDI quattro | 2006 – 2016 | 2967 | 171 | 233 |
| AUDI | Q7 (4LB) | 4.2 FSI quattro | 2006 – 2016 | 4163 | 257 | 350 |
| AUDI | Q7 (4LB) | 3.0 TFSI quattro | 2006 – 2016 | 2995 | 206 | 280 |
| AUDI | Q7 (4LB) | 3.0 TDI quattro | 2006 – 2016 | 2967 | 165 | 224 |
| AUDI | Q7 (4LB) | 4.2 TDI quattro | 2006 – 2016 | 4134 | 240 | 326 |
| AUDI | Q7 Van (4LB) | 6.0 TDI quattro | 2006 – 2016 | 5934 | 368 | 500 |
| AUDI | Q7 Van (4LB) | 4.2 FSI quattro | 2006 – 2016 | 4163 | 257 | 350 |
| AUDI | Q7 Van (4LB) | 4.2 TDI quattro | 2006 – 2016 | 4134 | 250 | 340 |
| AUDI | Q7 Van (4LB) | 4.2 TDI quattro | 2006 – 2016 | 4134 | 240 | 326 |
| AUDI | Q7 Van (4LB) | 3.6 FSI quattro | 2006 – 2016 | 3597 | 206 | 280 |
| AUDI | Q7 Van (4LB) | 3.0 TFSI quattro | 2006 – 2016 | 2995 | 245 | 333 |
| AUDI | Q7 Van (4LB) | 3.0 TDI quattro | 2006 – 2016 | 2967 | 180 | 245 |
| AUDI | Q7 Van (4LB) | 3.0 TDI quattro | 2006 – 2016 | 2967 | 176 | 240 |
| AUDI | Q7 Van (4LB) | 3.0 TDI quattro | 2006 – 2016 | 2967 | 171 | 232 |
| AUDI | Q7 Van (4LB) | 3.0 TDI quattro | 2006 – 2016 | 2967 | 155 | 211 |
| AUDI | Q7 Van (4LB) | 3.0 TDI quattro | 2006 – 2016 | 2967 | 150 | 204 |
