Specifications
| Bolt Hole Circle Ø (mm) | 86 |
| Bore Diameter (mm) | 10 |
| Diameter 2 (mm) | 100 |
| External Toothing wheel side 30 | |
| Length (mm) | 618 |
| Number of bores 6 | |
| Sealing Ring Diameter (mm) | 59 |
| Thread Size M27x1.5 | |
| Transmission-sided joint diameter (mm) | 102 |
| Wheel-sided joint diameter (mm) | 88 |
Bolt Hole Circle Ø [mm] 86, Bore Diameter [mm] 10, Diameter 2 [mm] 100, External Toothing wheel side 30, Length [mm] 618, Number of bores 6, Sealing Ring Diameter [mm] 59, Thread Size M27x1.5, Transmission-sided joint diameter [mm] 102, Wheel-sided joint diameter [mm] 88
Fits: BMW
Fits: BMW
Interchangeable Part Numbers
OE Numbers — BMW
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| BMW | X1 (E84) | xDrive 18 d | 2009 – 2015 | 1995 | 100 | 136 |
| BMW | X1 (E84) | xDrive 28 i | 2009 – 2015 | 2996 | 194 | 264 |
| BMW | X1 (E84) | xDrive 28 i Flex | 2009 – 2015 | 1997 | 180 | 245 |
| BMW | X1 (E84) | sDrive 20 i Flex | 2009 – 2015 | 1997 | 135 | 184 |
| BMW | X1 (E84) | xDrive 35 i | 2009 – 2015 | 2979 | 225 | 306 |
| BMW | X1 (E84) | sDrive 16 i | 2009 – 2015 | 1592 | 105 | 143 |
| BMW | X1 (E84) | sDrive 20 d | 2009 – 2015 | 1995 | 135 | 184 |
| BMW | X1 (E84) | xDrive 20 d | 2009 – 2015 | 1995 | 135 | 184 |
| BMW | X1 (E84) | sDrive 16 d | 2009 – 2015 | 1995 | 85 | 116 |
| BMW | X1 (E84) | xDrive 25 d | 2009 – 2015 | 1995 | 160 | 218 |
| BMW | X1 (E84) | sDrive 28 i | 2009 – 2015 | 1997 | 180 | 245 |
| BMW | X1 (E84) | xDrive 25 i | 2009 – 2015 | 2996 | 160 | 218 |
| BMW | X1 (E84) | sDrive 18 i | 2009 – 2015 | 1995 | 110 | 150 |
| BMW | X1 (E84) | xDrive 28 i | 2009 – 2015 | 1997 | 180 | 245 |
| BMW | X1 (E84) | sDrive 18 d | 2009 – 2015 | 1995 | 100 | 136 |
| BMW | X1 (E84) | sDrive 20 d | 2009 – 2015 | 1995 | 120 | 163 |
| BMW | X1 (E84) | xDrive 20 d | 2009 – 2015 | 1995 | 120 | 163 |
| BMW | X1 (E84) | xDrive 23 d | 2009 – 2015 | 1995 | 150 | 204 |
| BMW | X1 (E84) | sDrive 20 d | 2009 – 2015 | 1995 | 130 | 177 |
| BMW | X1 (E84) | xDrive 20 d | 2009 – 2015 | 1995 | 130 | 177 |
| BMW | X1 (E84) | xDrive 18 d | 2009 – 2015 | 1995 | 105 | 143 |
| BMW | X1 (E84) | sDrive 18 d | 2009 – 2015 | 1995 | 105 | 143 |
| BMW | X1 (E84) | xDrive 28 i | 2009 – 2015 | 2996 | 190 | 258 |
| BMW | X1 (E84) | sDrive 18 i | 2009 – 2015 | 1995 | 100 | 136 |
| BMW | X1 (E84) | xDrive 20 i | 2009 – 2015 | 1997 | 135 | 184 |
| BMW | X1 (E84) | sDrive 20 i | 2009 – 2015 | 1997 | 135 | 184 |
