Specifications
| Core Depth (mm) | 29 |
| Core Length (mm) | 590 |
| Core Width (mm) | 383 |
| Heating/Cooling for vehicles with oil cooler | |
| Housing Type Synthetic Material Housing | |
| Inlet Ø (mm) | 37 |
| Material Copper | |
| Outlet Ø (mm) | 37 |
| Supplementary Article/Info 2 without coolant regulator | |
| Weight (kg) | 6.32 |
Core Depth [mm] 29, Core Length [mm] 590, Core Width [mm] 383, Heating/Cooling for vehicles with oil cooler, Housing Type Synthetic Material Housing, Inlet Ø [mm] 37, Material Copper, Outlet Ø [mm] 37, Supplementary Article/Info 2 without coolant regulator, Weight [kg] 6,32
