Specifications
| Core Depth (mm) | 17 |
| Core Length (mm) | 595 |
| Core Width (mm) | 320 |
| Heating/Cooling for vehicles without oil cooler | |
| Housing Type Synthetic Material Housing | |
| Inlet Ø (mm) | 32 |
| Material Aluminium | |
| Outlet Ø (mm) | 32 |
| Supplementary Article/Info 2 without coolant regulator | |
| Weight (kg) | 6.27 |
Core Depth [mm] 17, Core Length [mm] 595, Core Width [mm] 320, Heating/Cooling for vehicles without oil cooler, Housing Type Synthetic Material Housing, Inlet Ø [mm] 32, Material Aluminium, Outlet Ø [mm] 32, Supplementary Article/Info 2 without coolant regulator, Weight [kg] 6,27
