Specifications
| Component Number 4BB-1238-I 1.00, for bearing clearance from (mm) | 0.038. for housing diameter from [mm] 72.987. for shaft diameter from [mm] 68.987. for wall thickness from [mm] 2.455. to bearing clearance [mm] 0.116. to housing diameter [mm] 73.013. to shaft diameter [mm] 69.013. to wall thickness [mm] 2.468 |
| Width from (mm) | 26.87 |
| Width to (mm) | 27.13 |
Component Number 4BB-1238-I 1.00, for bearing clearance from [mm] 0,038, for housing diameter from [mm] 72,987, for shaft diameter from [mm] 68,987, for wall thickness from [mm] 2,455, to bearing clearance [mm] 0,116, to housing diameter [mm] 73,013, to shaft diameter [mm] 69,013, to wall thickness [mm] 2,468, Width from [mm] 26,87, Width to [mm] 27,13
