Specifications
| Component Number 4BB-1344-S, for bearing clearance from (mm) | 0.022. for housing diameter from [mm] 62.433. for shaft diameter from [mm] 58.725. for wall thickness from [mm] 1.823. to bearing clearance [mm] 0.075. to housing diameter [mm] 62.446. to shaft diameter [mm] 58.745. to wall thickness [mm] 1.833 |
| Width from (mm) | 27.75 |
| Width to (mm) | 28.0 |
Component Number 4BB-1344-S, for bearing clearance from [mm] 0,022, for housing diameter from [mm] 62,433, for shaft diameter from [mm] 58,725, for wall thickness from [mm] 1,823, to bearing clearance [mm] 0,075, to housing diameter [mm] 62,446, to shaft diameter [mm] 58,745, to wall thickness [mm] 1,833, Width from [mm] 27,75, Width to [mm] 28,0
