Specifications
| Component Number 12BB-1317-C, for bearing clearance from (mm) | 0.038. for housing diameter from [mm] 84.226. for shaft diameter from [mm] 79.35. for wall thickness from [mm] 2.394. to bearing clearance [mm] 0.114. to housing diameter [mm] 84.239. to shaft diameter [mm] 79.375. to wall thickness [mm] 2.407 |
| Width from (mm) | 43.97 |
| Width to (mm) | 44.2 |
Component Number 12BB-1317-C, for bearing clearance from [mm] 0,038, for housing diameter from [mm] 84,226, for shaft diameter from [mm] 79,35, for wall thickness from [mm] 2,394, to bearing clearance [mm] 0,114, to housing diameter [mm] 84,239, to shaft diameter [mm] 79,375, to wall thickness [mm] 2,407, Width from [mm] 43,97, Width to [mm] 44,2
