Specifications
| Component Number 1BB-1318-C, for bearing clearance from (mm) | 0.038. for housing diameter from [mm] 83.122. for shaft diameter from [mm] 79.35. for wall thickness from [mm] 1.839. to bearing clearance [mm] 0.114. to housing diameter [mm] 83.134. to shaft diameter [mm] 79.375. to wall thickness [mm] 1.852 |
| Width from (mm) | 50.165 |
| Width to (mm) | 50.165 |
Component Number 1BB-1318-C, for bearing clearance from [mm] 0,038, for housing diameter from [mm] 83,122, for shaft diameter from [mm] 79,35, for wall thickness from [mm] 1,839, to bearing clearance [mm] 0,114, to housing diameter [mm] 83,134, to shaft diameter [mm] 79,375, to wall thickness [mm] 1,852, Width from [mm] 50,165, Width to [mm] 50,165
