Specifications
| Component Number 12BB-1320-C 0.50, for bearing clearance from (mm) | 0.024. for housing diameter from [mm] 83.983. for shaft diameter from [mm] 78.987. for wall thickness from [mm] 2.698. to bearing clearance [mm] 0.108. to housing diameter [mm] 84.017. to shaft diameter [mm] 79.013. to wall thickness [mm] 2.704 |
| Width from (mm) | 41.83 |
| Width to (mm) | 42.21 |
Component Number 12BB-1320-C 0.50, for bearing clearance from [mm] 0,024, for housing diameter from [mm] 83,983, for shaft diameter from [mm] 78,987, for wall thickness from [mm] 2,698, to bearing clearance [mm] 0,108, to housing diameter [mm] 84,017, to shaft diameter [mm] 79,013, to wall thickness [mm] 2,704, Width from [mm] 41,83, Width to [mm] 42,21
