Specifications
| Component Number 6BB-496-P 0.50, for bearing clearance from (mm) | 0.031. for housing diameter from [mm] 74.707. for shaft diameter from [mm] 69.84. for wall thickness from [mm] 2.645. to bearing clearance [mm] 0.077. to housing diameter [mm] 74.717. to shaft diameter [mm] 69.85. to wall thickness [mm] 2.658 |
| Width from (mm) | 35.81 |
Component Number 6BB-496-P 0.50, for bearing clearance from [mm] 0,031, for housing diameter from [mm] 74,707, for shaft diameter from [mm] 69,84, for wall thickness from [mm] 2,645, to bearing clearance [mm] 0,077, to housing diameter [mm] 74,717, to shaft diameter [mm] 69,85, to wall thickness [mm] 2,658, Width from [mm] 35,81
