Specifications
| Component Number 8BB-1072-C 0.25, for bearing clearance from (mm) | 0.02. for housing diameter from [mm] 47.0. for shaft diameter from [mm] 43.992. for wall thickness from [mm] 1.611. to bearing clearance [mm] 0.044. to housing diameter [mm] 47.024. to shaft diameter [mm] 44.0. to wall thickness [mm] 1.623 |
| Width from (mm) | 15.5 |
| Width to (mm) | 15.7 |
Component Number 8BB-1072-C 0.25, for bearing clearance from [mm] 0,02, for housing diameter from [mm] 47,0, for shaft diameter from [mm] 43,992, for wall thickness from [mm] 1,611, to bearing clearance [mm] 0,044, to housing diameter [mm] 47,024, to shaft diameter [mm] 44,0, to wall thickness [mm] 1,623, Width from [mm] 15,5, Width to [mm] 15,7
