Specifications
| Component Number 10BB-1363-C 1.00, for bearing clearance from (mm) | 0.05. for housing diameter from [mm] 91.23. for shaft diameter from [mm] 86.978. for wall thickness from [mm] 2.58. to bearing clearance [mm] 0.114. to housing diameter [mm] 91.252. to shaft diameter [mm] 87.0. to wall thickness [mm] 2.59 |
| Width from (mm) | 44.8 |
| Width to (mm) | 45.2 |
Component Number 10BB-1363-C 1.00, for bearing clearance from [mm] 0,05, for housing diameter from [mm] 91,23, for shaft diameter from [mm] 86,978, for wall thickness from [mm] 2,58, to bearing clearance [mm] 0,114, to housing diameter [mm] 91,252, to shaft diameter [mm] 87,0, to wall thickness [mm] 2,59, Width from [mm] 44,8, Width to [mm] 45,2
