Specifications
| Component Number 8BB-2012-C0.50, for bearing clearance from (mm) | 0.014. for housing diameter from [mm] 45.0. for shaft diameter from [mm] 41.95. for wall thickness from [mm] 1.75. to bearing clearance [mm] 0.07. to housing diameter [mm] 45.02. to shaft diameter [mm] 41.97. to wall thickness [mm] 1.758 |
| Width from (mm) | 14.25 |
| Width to (mm) | 14.5 |
Component Number 8BB-2012-C0.50, for bearing clearance from [mm] 0,014, for housing diameter from [mm] 45,0, for shaft diameter from [mm] 41,95, for wall thickness from [mm] 1,75, to bearing clearance [mm] 0,07, to housing diameter [mm] 45,02, to shaft diameter [mm] 41,97, to wall thickness [mm] 1,758, Width from [mm] 14,25, Width to [mm] 14,5
