Brake Disc
Brake Disc 1 Brake Disc 2 Brake Disc 3
Braking System

Brake Disc

Part No. BG3527 · SKU BG3527-DELPHI
Front Axle
₱24,100.00
In stock — available to order
Genuine & OEM parts Nationwide delivery Easy returns

Specifications

Brake Disc Thickness (mm)22
Brake Disc Type Vented
Centering Diameter (mm)79
Height (mm)51.6
Minimum thickness (mm)20.4
Number of Holes 5
Outer Diameter (mm)300
Surface Oiled
Test Mark E4 90R-02C0703/2628
Brake Disc Thickness [mm] 22, Brake Disc Type Vented, Centering Diameter [mm] 79, Height [mm] 51,6, Minimum thickness [mm] 20,4, Number of Holes 5, Outer Diameter [mm] 300, Surface Oiled, Test Mark E4 90R-02C0703/2628
Fits: BMW

Supplier Cross-References

BMW / MINI34116864058 DELPHIBG3527 ZIMMERMANN150128800 FERODODDF1066 ATE24012201601 HELLA PAGID355106541

Interchangeable Part Numbers

A.B.S.17023 ACDelcoAC2410D ALFA DR6591 ALFADR6591 AP 24746V AP24746V APECDSK971 APECSDK6103 ATE-CN24-0122-0160-1-02 ATE-CN422160 BARUMBAR22160 BENDIX562090 BENDIX562090B BLUE PRINTADB114305 BOSCH 0 986 478571 BOSCH0986478571 BOSCH 0 986 479S32 BOSCH0986479S32 BRADI1.0644.2.4 Brake ENGINEERING955915 Brake ENGINEERINGDI955915 Brake ENGINEERINGDI955915S BREMBO09.7701.10 BREMBO09.7701.11 BREMBO09.7701.75 BREMBOFD.091.000 BREMBOFS.091.000 CAR142.094 CIFAM800-515 COMLINEADC1712V FEBI BILSTEIN12323 fri.tech.DF549 FTEBS5146 GIRLING6040551 GRAFDF29515 HP (ZEBRA)57882 JURATEKBMW106 JURID562090J KAGER37-1067 LEMFÖRDER22830 LEMFÖRDER 2283002 LEMFÖRDER2283002 MAGNETI MARELLI353610644240 METELLI23-0515 MEYLE 315 5213020/PD MEYLE3155213020PD MEYLE 315 5213020 MEYLE3155213020 MGAD1315 MINTEXMDC1383 MOTAQUIPVBE271 NationalNBD976 NECTOWN1070 NK201540 PAGID50448 PEX14.0113 PILENGAV128 QUINTON HAZELLBDC5146 QUINTON HAZELLBDC5146HC QUINTON HAZELLBDC5146P ROADHOUSE6589.10 ROULUNDS BRAKINGD2410 sbs1815201540 SEBRO202418 TEXTAR92097200 TEXTAR92097205 TOPRAN 500572 TOPRAN500572 TRWDF4055 UNIPARTGBD1125 VAICOV20-80043 VALEO186815

OE Numbers — BMW 3411 1164

539

OE Numbers — BMW

34111164539 34116757526 34116766224 34116794302 34116855152

OE Numbers — BMW 3411 6757

526

OE Numbers — BMW 3411 6766

224
MakeModelType / Engine YearsCCkWHP
BMW 3 (E46) 325 i 1997 – 2005 2494 132 179
BMW 3 (E46) 330 xi 1997 – 2005 2979 168 228
BMW 3 (E46) 320 d 1997 – 2005 1951 95 129
BMW 3 (E46) 323 i 1997 – 2005 2494 120 163
BMW 3 (E46) 328 i 1997 – 2005 2793 144 196
BMW 3 (E46) 320 i 1997 – 2005 2171 120 163
BMW 3 (E46) 325 i 1997 – 2005 2494 137 186
BMW 3 (E46) 318 i 1997 – 2005 1995 100 136
BMW 3 (E46) 318 i 1997 – 2005 1895 87 118
BMW 3 (E46) 328 i 1997 – 2005 2793 142 193
BMW 3 (E46) 320 d 1997 – 2005 1951 100 136
BMW 3 (E46) 323 i 1997 – 2005 2494 125 170
BMW 3 (E46) 320 i 1997 – 2005 1990 110 150
BMW 3 (E46) 316 i 1997 – 2005 1895 77 105
BMW 3 (E46) 330 d 1997 – 2005 2926 135 184
BMW 3 (E46) 330 xd 1997 – 2005 2926 135 184
BMW 3 (E46) 330 xi 1997 – 2005 2979 170 231
BMW 3 (E46) 330 i 1997 – 2005 2979 170 231
BMW 3 (E46) 320 i 1997 – 2005 2171 125 170
BMW 3 (E46) 325 i 1997 – 2005 2494 141 192
BMW 3 (E46) 325 xi 1997 – 2005 2494 141 192
BMW 3 (E46) 316 i 1997 – 2005 1596 77 105
BMW 3 (E46) 318 i 1997 – 2005 1995 105 143
BMW 3 (E46) 320 d 1997 – 2005 1995 110 150
BMW 3 (E46) 318 d 1997 – 2005 1951 85 116
BMW 3 (E46) 316 i 1997 – 2005 1796 85 115
BMW 3 (E46) 330 d 1997 – 2005 2993 150 204
BMW 3 (E46) 330 xd 1997 – 2005 2993 150 204
BMW 3 (E46) 318 d 1997 – 2005 1995 85 116
BMW 3 (E46) 316 i 1997 – 2005 1596 85 115
BMW 3 (E46) 325 xi 1997 – 2005 2494 137 186
BMW 3 Compact (E46) 316 ti 2001 – 2005 1796 85 115
BMW 3 Compact (E46) 325 ti 2001 – 2005 2494 141 192
BMW 3 Compact (E46) 318 ti 2001 – 2005 1995 105 143
BMW 3 Compact (E46) 320 td 2001 – 2005 1995 110 150
BMW 3 Compact (E46) 318 td 2001 – 2005 1995 85 115
BMW 3 Compact (E46) 320 td 2001 – 2005 1995 100 136
BMW 3 Compact (E46) 316 ti 2001 – 2005 1596 77 105
BMW 3 Compact (E46) 316 ti 2001 – 2005 1596 85 115
BMW 3 Compact (E46) 318 ti 2001 – 2005 1995 100 136
BMW 3 Convertible (E46) 320 Ci 2000 – 2007 2171 120 163
BMW 3 Convertible (E46) 330 Ci 2000 – 2007 2979 168 228
BMW 3 Convertible (E46) 318 Ci 2000 – 2007 1995 100 136
BMW 3 Convertible (E46) 323 Ci 2000 – 2007 2494 120 163
BMW 3 Convertible (E46) 323 Ci 2000 – 2007 2494 125 170
BMW 3 Convertible (E46) 330 Ci 2000 – 2007 2979 170 231
BMW 3 Convertible (E46) 320 Ci 2000 – 2007 2171 125 170
BMW 3 Convertible (E46) 325 Ci 2000 – 2007 2494 141 192
BMW 3 Convertible (E46) M3 2000 – 2007 3246 252 343
BMW 3 Convertible (E46) 318 Ci 2000 – 2007 1995 105 143
BMW 3 Convertible (E46) 320 Cd 2000 – 2007 1995 110 150
BMW 3 Convertible (E46) 330 Cd 2000 – 2007 2993 150 204
BMW 3 Convertible (E46) 318 Ci 2000 – 2007 1995 110 150
BMW 3 Convertible (E46) 325 Ci 2000 – 2007 2494 137 186
BMW 3 Coupe (E46) 323 Ci 1998 – 2006 2494 125 170
BMW 3 Coupe (E46) 328 Ci 1998 – 2006 2793 142 193
BMW 3 Coupe (E46) 320 Ci 1998 – 2006 1990 110 150
BMW 3 Coupe (E46) 318 Ci 1998 – 2006 1895 87 118
BMW 3 Coupe (E46) M3 1998 – 2006 3246 252 343
BMW 3 Coupe (E46) 330 xi 1998 – 2006 2979 170 231
BMW 3 Coupe (E46) 320 Ci 1998 – 2006 2171 125 170
BMW 3 Coupe (E46) 325 Ci 1998 – 2006 2494 141 192
BMW 3 Coupe (E46) 316 Ci 1998 – 2006 1596 77 105
BMW 3 Coupe (E46) 318 Ci 1998 – 2006 1995 105 143
BMW 3 Coupe (E46) 330 Cd 1998 – 2006 2993 150 204
BMW 3 Coupe (E46) 320 Cd 1998 – 2006 1995 110 150
BMW 3 Coupe (E46) M3 CSL 1998 – 2006 3246 265 360
BMW 3 Coupe (E46) 316 Ci 1998 – 2006 1596 85 115
BMW 3 Coupe (E46) 318 Ci 1998 – 2006 1995 110 150
BMW 3 Coupe (E46) 330 Ci 1998 – 2006 2979 170 231
BMW 3 Coupe (E46) 325 Ci 1998 – 2006 2494 137 186
BMW 3 Coupe (E46) 318 Ci 1998 – 2006 1895 85 116
BMW 3 Coupe (E46) 318 Ci 1998 – 2006 1995 100 136
BMW 3 Coupe (E46) 318 Ci 1998 – 2006 1895 103 140
BMW 3 Coupe (E46) 323 Ci 1998 – 2006 2494 120 163
BMW 3 Coupe (E46) 325 i 1998 – 2006 2494 132 179
BMW 3 Coupe (E46) 320 Ci 1998 – 2006 2171 120 163
BMW 3 Coupe (E46) 323 i 1998 – 2006 2494 127 173
BMW 3 Coupe (E46) 330 Ci 1998 – 2006 2979 168 228
BMW 3 Touring (E46) 320 i 1999 – 2005 2171 120 163
BMW 3 Touring (E46) 318 i 1999 – 2005 1895 85 116
BMW 3 Touring (E46) 325 i 1999 – 2005 2494 132 179
BMW 3 Touring (E46) 320 i 1999 – 2005 1990 110 150
BMW 3 Touring (E46) 318 i 1999 – 2005 1895 87 118
BMW 3 Touring (E46) 328 i 1999 – 2005 2793 142 193
BMW 3 Touring (E46) 320 d 1999 – 2005 1951 100 136
BMW 3 Touring (E46) 330 d 1999 – 2005 2926 135 184
BMW 3 Touring (E46) 330 xd 1999 – 2005 2926 135 184
BMW 3 Touring (E46) 330 xi 1999 – 2005 2979 170 231
BMW 3 Touring (E46) 330 i 1999 – 2005 2979 170 231
BMW 3 Touring (E46) 320 i 1999 – 2005 2171 125 170
BMW 3 Touring (E46) 325 i 1999 – 2005 2494 141 192
BMW 3 Touring (E46) 325 xi 1999 – 2005 2494 141 192
BMW 3 Touring (E46) 320 d 1999 – 2005 1995 110 150
BMW 3 Touring (E46) 318 i 1999 – 2005 1995 105 143
BMW 3 Touring (E46) 316 i 1999 – 2005 1796 85 115
BMW 3 Touring (E46) 318 d 1999 – 2005 1951 85 115
BMW 3 Touring (E46) 330 d 1999 – 2005 2993 150 204
BMW 3 Touring (E46) 330 xd 1999 – 2005 2993 150 204
BMW 3 Touring (E46) 318 d 1999 – 2005 1995 85 116
BMW 3 Touring (E46) 323 i 1999 – 2005 2494 125 170
BMW 3 Touring (E46) 325 i 1999 – 2005 2494 137 186
BMW 3 Touring (E46) 325 xi 1999 – 2005 2494 137 186
BMW Z3 Coupe (E36) 2.8 i 1997 – 2003 2793 142 193
BMW Z3 Coupe (E36) M 1997 – 2003 3201 236 321
BMW Z3 Coupe (E36) 3.0 i 1997 – 2003 2979 170 231
BMW Z3 Coupe (E36) M 1997 – 2003 3246 239 325
BMW Z3 Coupe (E36) M 1997 – 2003 3246 235 320
BMW Z3 Coupe (E36) 3.0 i 1997 – 2003 2979 168 228
BMW Z3 Coupe (E36) M 3.2 1997 – 2003 3152 176 239
BMW Z3 Roadster (E36) 2.2 i 1995 – 2003 2171 120 163
BMW Z3 Roadster (E36) 3.0 i 1995 – 2003 2979 168 228
BMW Z3 Roadster (E36) 2.5 1995 – 2003 2494 125 170
BMW Z3 Roadster (E36) 1.9 i 1995 – 2003 1895 103 140
BMW Z3 Roadster (E36) 1.8 i 1995 – 2003 1796 85 116
BMW Z3 Roadster (E36) 2.8 i 1995 – 2003 2793 142 193
BMW Z3 Roadster (E36) M 3.2 1995 – 2003 3201 236 321
BMW Z3 Roadster (E36) 1.9 i 1995 – 2003 1895 87 118
BMW Z3 Roadster (E36) 2.0 i 1995 – 2003 1990 110 150
BMW Z3 Roadster (E36) 1.9 i 1995 – 2003 1895 85 116
BMW Z3 Roadster (E36) 3.0 i 1995 – 2003 2979 170 231
BMW Z3 Roadster (E36) 2.2 i 1995 – 2003 2171 125 170
BMW Z3 Roadster (E36) M 3.2 1995 – 2003 3246 239 325
BMW Z3 Roadster (E36) M 3.2 1995 – 2003 3152 179 243
BMW Z3 Roadster (E36) 2.5 i 1995 – 2003 2494 141 192
BMW Z3 Roadster (E36) 3.2 i 1995 – 2003 3246 235 320
BMW Z4 Roadster (E85) 3.0 si 2002 – 2009 2996 190 258
BMW Z4 Roadster (E85) 3.2 2002 – 2009 3246 235 320
BMW Z4 Roadster (E85) 3.0 i 2002 – 2009 2979 170 231
BMW Z4 Roadster (E85) 2.5 i 2002 – 2009 2494 141 192
BMW Z4 Roadster (E85) 2.2 i 2002 – 2009 2171 125 170
BMW Z4 Roadster (E85) 2.0 i 2002 – 2009 1995 110 150
BMW Z4 Roadster (E85) 2.5 i 2002 – 2009 2497 130 177
BMW Z4 Roadster (E85) 2.5 si 2002 – 2009 2497 160 218
BMW Z4 Roadster (E85) 3.0 si 2002 – 2009 2996 195 265
BMW Z4 Roadster (E85) M 2002 – 2009 3246 252 343
BMW Z4 Roadster (E85) 2.5 si 2002 – 2009 2497 155 211
BMW Z4 Roadster (E85) 3.0 si 2002 – 2009 2996 160 218
