Brake Disc
Brake Disc 1 Brake Disc 2 Brake Disc 3
Braking System

Brake Disc

Part No. BG3755 · SKU BG3755-DELPHI
Front Axle
₱27,000.00
In stock — available to order
Genuine & OEM parts Nationwide delivery Easy returns

Specifications

Brake Disc Thickness (mm)28
Brake Disc Type Vented
Centering Diameter (mm)67
Height (mm)54.5
Minimum thickness (mm)25.4
Number of Holes 5
Outer Diameter (mm)295
Test Mark E1 90R-02C0343/1201
Brake Disc Thickness [mm] 28, Brake Disc Type Vented, Centering Diameter [mm] 67, Height [mm] 54,5, Minimum thickness [mm] 25,4, Number of Holes 5, Outer Diameter [mm] 295, Test Mark E1 90R-02C0343/1201
Fits: MERCEDES-BENZ

Supplier Cross-References

DELPHIBG3755 ZIMMERMANN400361800 FERODODDF12521 ATE24012801411 HELLA PAGID355108771 JURID562212J

Interchangeable Part Numbers

A.B.S.17400 AP24897 E APECDSK2195 APECDSK2224 ATE-CN24-0128-0141-1-02 ATE-CN24-0128-0176-1-02 ATE-CN24.0128-0176.1 ATE-CN428141 ATE-CN428176 BARUMBAR28176 BENDIX562212B Brake ENGINEERINGDI956275 Brake ENGINEERINGDI956282 BREMBO09.9362.10 BREMBO09.9362.11 BREMBO09.9362.14 CAR142.386 CIFAM800-600 COMLINEADC1623V FEBI BILSTEIN22156 FEBI BILSTEIN22158 FERODODDF1252 FREMAXBD-0812 fri.tech.DF927 fri.tech.DF958 FTEBS5414 FTEBS5464 GIRLING6042611 GRAFDF29600 HP (ZEBRA)58144 JURATEKMER178 KAGER37-1131 MAGNETI MARELLI351286820500 MEYLE015 521 2051/PD MEYLE015 521 2051 MEYLE015 521 2052/PD MEYLE015 521 2052 MGAD1540 MINTEXMDC1616 MINTEXMDC1977 MOTAQUIPVBD1032 NationalNBD1239 NK203358 NK203359 PAGID54151 PAGID54152 PEX14.0714 PEX14.0814 PILENGAV295 QUINTON HAZELLBDC5414 QUINTON HAZELLBDC5414HC QUINTON HAZELLBDC5414P QUINTON HAZELLBDC5464 QUINTON HAZELLBDC5464P REMSA6676.10 sbs1815203358 sbs1815203359 TEXTAR92115100 TEXTAR92115200 TOPRAN401 051 TOPRAN401 052 TRWDF4261 TRWDF4261BP VAICOV30-80047 VAICOV30-80048 VALEO186751 WOKINGP6676.10 ZIMMERMANN400.3619.00 ZIMMERMANN400.3619.50

OE Numbers — MERCEDES-BENZ

211 421 0712 211 421 081264 211 421 0812 A211 421 0712 A211 421 081264 A211 421 0812
MakeModelType / Engine YearsCCkWHP
MERCEDES-BENZ E-CLASS (W211) E 500 4-matic (211.090) 2002 – 2009 5461 285 388
MERCEDES-BENZ E-CLASS (W211) E 280 CDI (211.023) 2002 – 2009 3222 130 177
MERCEDES-BENZ E-CLASS (W211) E 280 (211.054) 2002 – 2009 2996 170 231
MERCEDES-BENZ E-CLASS (W211) E 350 (211.056) 2002 – 2009 3498 200 272
MERCEDES-BENZ E-CLASS (W211) E 280 CDI (211.020) 2002 – 2009 2987 140 190
MERCEDES-BENZ E-CLASS (W211) E 320 CDI (211.022) 2002 – 2009 2987 165 224
MERCEDES-BENZ E-CLASS (W211) E 280 CDI 4-matic (211.084) 2002 – 2009 2987 140 190
MERCEDES-BENZ E-CLASS (W211) E 420 CDI (211.029) 2002 – 2009 3996 231 314
MERCEDES-BENZ E-CLASS (W211) E 280 4-matic (211.092) 2002 – 2009 2996 170 231
MERCEDES-BENZ E-CLASS (W211) E 350 4-matic (211.087) 2002 – 2009 3498 200 272
MERCEDES-BENZ E-CLASS (W211) E 320 CDI 4-matic (211.089) 2002 – 2009 2987 165 224
MERCEDES-BENZ E-CLASS (W211) E 200 CDI (211.007) 2002 – 2009 2148 100 136
MERCEDES-BENZ E-CLASS (W211) E 220 CDI (211.008) 2002 – 2009 2148 125 170
MERCEDES-BENZ E-CLASS (W211) E 200 Kompressor (211.041) 2002 – 2009 1796 135 184
MERCEDES-BENZ E-CLASS (W211) E 220 CDI 2002 – 2009 2149 120 163
MERCEDES-BENZ E-CLASS (W211) E 500 (211.072) 2002 – 2009 5461 285 388
MERCEDES-BENZ E-CLASS (W211) E 63 AMG (211.077) 2002 – 2009 6208 378 514
MERCEDES-BENZ E-CLASS (W211) E 220 CDI (211.006) 2002 – 2009 2148 100 136
MERCEDES-BENZ E-CLASS (W211) E 350 CGI (211.057) 2002 – 2009 3498 215 292
MERCEDES-BENZ E-CLASS (W211) E 300 BlueTEC (211.024) 2002 – 2009 2987 155 211
MERCEDES-BENZ E-CLASS (W211) E 230 (211.052) 2002 – 2009 2496 150 204
MERCEDES-BENZ E-CLASS (W211) E 350 4-matic (211.087) 2002 – 2009 3498 205 279
MERCEDES-BENZ E-CLASS (W211) E 500 (211.070) 2002 – 2009 4966 215 292
MERCEDES-BENZ E-CLASS (W211) E320 CDI (211.022) 2002 – 2009 2987 156 212
MERCEDES-BENZ E-CLASS (W211) E 270 CDI (211.016) 2002 – 2009 2685 120 163
MERCEDES-BENZ E-CLASS (W211) E 320 BlueTEC (211.022) 2002 – 2009 2987 156 212
MERCEDES-BENZ E-CLASS (W211) E 63 AMG (211.077) 2002 – 2009 6208 378 514
MERCEDES-BENZ E-CLASS (W211) E 240 (211.061) 2002 – 2009 2597 120 163
MERCEDES-BENZ E-CLASS (W211) E 240 (211.061) 2002 – 2009 2597 130 177
MERCEDES-BENZ E-CLASS (W211) E 200 CDI (211.004) 2002 – 2009 2148 75 102
MERCEDES-BENZ E-CLASS (W211) E 320 4-matic (211.082) 2002 – 2009 3199 165 224
MERCEDES-BENZ E-CLASS (W211) E 200 CDI (211.004) 2002 – 2009 2148 90 122
MERCEDES-BENZ E-CLASS (W211) E 55 AMG Kompressor (211.076) 2002 – 2009 5439 350 476
MERCEDES-BENZ E-CLASS (W211) E 200 Kompressor (211.042) 2002 – 2009 1796 120 163
MERCEDES-BENZ E-CLASS (W211) E 240 4-matic (211.080) 2002 – 2009 2597 130 177
MERCEDES-BENZ E-CLASS (W211) E 320 CDI (211.026) 2002 – 2009 3222 150 204
MERCEDES-BENZ E-CLASS (W211) E 270 CDI (211.016) 2002 – 2009 2685 130 177
MERCEDES-BENZ E-CLASS (W211) E 220 CDI (211.006) 2002 – 2009 2148 110 150
MERCEDES-BENZ E-CLASS (W211) E 400 CDI (211.028) 2002 – 2009 3996 191 260
MERCEDES-BENZ E-CLASS (W211) E 500 4-matic (211.083) 2002 – 2009 4966 225 306
MERCEDES-BENZ E-CLASS (W211) E 500 (211.070) 2002 – 2009 4966 225 306
MERCEDES-BENZ E-CLASS (W211) E 200 NGT (211.042) 2002 – 2009 1796 120 163
MERCEDES-BENZ E-CLASS (W211) E 320 (211.065) 2002 – 2009 3199 165 224
MERCEDES-BENZ E-CLASS Platform/Chassis (VF211) E 220 CDI (211.606) 2003 – 2009 2148 110 150
MERCEDES-BENZ E-CLASS Platform/Chassis (VF211) E 220 CDI (211.608) 2003 – 2009 2148 125 170
MERCEDES-BENZ E-CLASS Platform/Chassis (VF211) E 270 CDI (211.616) 2003 – 2009 2685 120 163
MERCEDES-BENZ E-CLASS Platform/Chassis (VF211) E 270 CDI (211.616) 2003 – 2009 2685 130 177
MERCEDES-BENZ E-CLASS Platform/Chassis (VF211) E 280 CDI (211.620) 2003 – 2009 2987 140 190
MERCEDES-BENZ E-CLASS T-Model (S211) E 240 T (211.261) 2003 – 2009 2597 120 163
MERCEDES-BENZ E-CLASS T-Model (S211) E 230 T (211.252) 2003 – 2009 2496 150 204
MERCEDES-BENZ E-CLASS T-Model (S211) 3.5 4-matic 2003 – 2009 3498 205 279
MERCEDES-BENZ E-CLASS T-Model (S211) 350 CGI (211.257) 2003 – 2009 3498 215 292
MERCEDES-BENZ E-CLASS T-Model (S211) E 240 T (211.261) 2003 – 2009 2597 130 177
MERCEDES-BENZ E-CLASS T-Model (S211) E 200 CDI (211.207) 2003 – 2009 2148 100 136
MERCEDES-BENZ E-CLASS T-Model (S211) E 320 T (211.265) 2003 – 2009 3199 165 224
MERCEDES-BENZ E-CLASS T-Model (S211) E 55 T AMG Kompressor 2003 – 2009 5439 350 476
MERCEDES-BENZ E-CLASS T-Model (S211) E 320 T CDI (211.222) 2003 – 2009 2987 155 211
MERCEDES-BENZ E-CLASS T-Model (S211) E 220 T CDI 2003 – 2009 2148 120 163
MERCEDES-BENZ E-CLASS T-Model (S211) E 270 T CDI (211.216) 2003 – 2009 2685 120 163
MERCEDES-BENZ E-CLASS T-Model (S211) E 280 T 4-matic (211.292) 2003 – 2009 2996 170 231
MERCEDES-BENZ E-CLASS T-Model (S211) E 280 T CDI (211.223) 2003 – 2009 3222 130 177
MERCEDES-BENZ E-CLASS T-Model (S211) E 500 T 4-matic (211.283) 2003 – 2009 4966 225 306
MERCEDES-BENZ E-CLASS T-Model (S211) E 500 T (211.270) 2003 – 2009 4966 225 306
MERCEDES-BENZ E-CLASS T-Model (S211) E 55 T AMG Kompressor (211.276) 2003 – 2009 5439 350 476
MERCEDES-BENZ E-CLASS T-Model (S211) E 320 T 4-matic (211.282) 2003 – 2009 3199 165 224
MERCEDES-BENZ E-CLASS T-Model (S211) E 320 T CDI (211.222) 2003 – 2009 2987 165 224
MERCEDES-BENZ E-CLASS T-Model (S211) E 280 T CDI (211.220) 2003 – 2009 2987 140 190
MERCEDES-BENZ E-CLASS T-Model (S211) E 280 T (211.254) 2003 – 2009 2996 170 231
MERCEDES-BENZ E-CLASS T-Model (S211) E 350 T (211.256) 2003 – 2009 3498 200 272
MERCEDES-BENZ E-CLASS T-Model (S211) E 240 T 4-matic (211.280) 2003 – 2009 2597 130 177
MERCEDES-BENZ E-CLASS T-Model (S211) E 280 T CDI 4-matic (211.284) 2003 – 2009 2987 140 190
MERCEDES-BENZ E-CLASS T-Model (S211) E 220 CDI (211.206) 2003 – 2009 2148 100 136
MERCEDES-BENZ E-CLASS T-Model (S211) E 320 T CDI (211.226) 2003 – 2009 3222 150 204
MERCEDES-BENZ E-CLASS T-Model (S211) E 320 T CDI 4-matic (211.289) 2003 – 2009 2987 165 224
MERCEDES-BENZ E-CLASS T-Model (S211) E 350 T 4-matic (211.287) 2003 – 2009 3498 200 272
MERCEDES-BENZ E-CLASS T-Model (S211) E 270 T CDI (211.216) 2003 – 2009 2685 130 177
MERCEDES-BENZ E-CLASS T-Model (S211) E 220 T CDI (211.206) 2003 – 2009 2148 110 150
MERCEDES-BENZ E-CLASS T-Model (S211) E 200 T Kompressor (211.242) 2003 – 2009 1796 120 163
MERCEDES-BENZ E-CLASS T-Model (S211) E 220 T CDI (211.208) 2003 – 2009 2148 125 170
MERCEDES-BENZ E-CLASS T-Model (S211) E 200 Kompressor (211.241) 2003 – 2009 1796 135 184
MERCEDES-BENZ E-CLASS T-Model (S211) E 500 T (211.272) 2003 – 2009 5461 285 388
MERCEDES-BENZ E-CLASS T-Model (S211) E 500 T 4-matic (211.290) 2003 – 2009 5461 285 388
MERCEDES-BENZ E-CLASS T-Model (S211) E 63 AMG (211.277) 2003 – 2009 6208 378 514
